Pfaff 491 - Pressure of Roller Presser

To Next Page

To Previous Page

Adjustment

11 - 33

11.04.29 Pressure of roller presser

Requirement

The material must be fed smoothly. No pressure marks should be visible on the material.

Fig. 11 - 29

● Adjust roller presser pressure with screw 1 according to the requirement.
