Pfaff 491 User Manual

Adjustment
11 - 70
6 601 Cut
l = yes l
ll = no
607 Max. speed 100 - 2800 2800
609 Cutting speed 1 30 - 300 180
7 700 Needle position 0 - 191
Needle reference position
701 Angle setting
I = Set synchronizer with l
balance wheel
II = Set synchronizer with
buttons " + " and " - "
702 Needle position 1 (needle lowered) 0 - 191 20
703 Needle position 2 0 - 191 175
(take-up lever raised)
707 Needle position 9 0 - 191 140
(Start tension release signal 2)
11.10 Parameter settings for the Quick-Ministop Motor
Parameters can be set on the operating panel via display.
Group
Parameter
Significance Setting Standard value
Further displays and information are available in the Motor Service Manual.
