Preparations
Preparations
Unpacking
1. Place the box on a steady, fl at surface. Lift
the machine out of the box, remove the outer
packaging and lift off the machine carrying
case.
2. Remove all outer packing material and the
plastic bag.
Note: Your PFAFF® ambition essential™ sewing
machine is adjusted to provide the best stitch result
at normal room temperature. Extreme hot and cold
temperatures can affect the sewn result.
Connect to the power supply
Among the accessories you will fi nd the power
cord and the foot control.
Note: Consult a qualifi ed electrician if in doubt as how
to connect the machine to the power source. Unplug the
power cord when the machine is not in use.
For this sewing machine, foot control model C-9002
manufactured by CHIENHUNG TAIWAN., LTD
must be used.
1. Connect the foot control cord to the front
socket on the bottom right side of the machine
(A).
The sewing speed is controlled by pressing the
foot control.
2. Connect the power cord to the rear socket on
the bottom right side of the machine (B). Plug
the cord into the wall socket.
3. Press the ON/OFF switch to ON to turn on
power and light (C).
Pack away after sewing
1. Switch the main switch off.
2. Unplug the cord from the wall socket and then
from the machine.
3. Unplug the foot control cord from the machine.
Wind the cord around the foot control for easy
storage.
4. Place all accessories in the accessory tray. Slide
the tray on to the machine around the free arm.
5. Place the foot control in the space above the
free arm.
6. Put on the hard cover.
For the USA and Canada
This sewing machine has a polarized plug (one
blade wider than the other). To reduce the risk
of electric shock, this plug is intended to fi t in a
polarized outlet only one way. If the plug does
not fi t fully in the outlet, reverse the plug. If it
still does not fi t, contact a qualifi ed electrician to
install the proper outlet. Do not modify the plug
in any way.
