1:4
B
C
A
D
Operate your hobby 1132/1122
Presser foot lifter
The presser foot is raised or lowered with
the presser foot lifter.
You can raise the foot about 1/4" (6 mm)
higher than the normal up position for
easy removal of the presser foot, or to
help you place heavy fabric under the
foot.
A Lowered position
B Normal up position
C Extra lift position
Changing the presser foot
Turn off the main switch.
Removing the presser foot
Raise the needle to its highest position by
turning the handwheel.
Raise the presser foot, and press the red
button on the back of the foot holder.
Engaging the presser foot
Place the desired presser foot, so that
when the presser foot lifter is lowered, the
pins (D) of the foot engage in the presser
foot holder.
Note: Check that the presser foot is properly
engaged by raising the presser foot lifter.
