1:8
A
B
D
E
C
Operate your hobby 1132/1122
Inserting the bobbin
Turn off the main switch.
Place the bobbin in the bobbin holder
with the thread running off as shown in
the picture.
Pull the thread into the front notch (A) on
the front side of the bobbin holder. Pull
the thread to the left, sliding it between
the tension spring blades.
Continue to pull the thread lightly until
the thread slips into the side notch (B).
Pull out about 10 cm (4”) of thread.
Attach the throat plate. Check the
threading by referring to the chart shown
on the throat plate (C).
Removing the bobbin
Push the throat plate release button (D) to
the right and remove the throat plate (E).
Lift out the bobbin.
