Movable up-
per blade
Upper overedge
looper (red)
Lower overedge
looper (yellow)
Standard presser foot
Bed slide for stitch
width latch
Fixed lower
blade
Thread chain cutter
Presser foot lifter
Needle plate
Ridged knob for lowering
the upper blade
Setting knob for
seam width
Parts of the hobbylock 4752
