Mixing pump RITMO L / RITMO M Overview - Operation
Intended use control panel
20
2016-02-17
13 Intended use control panel
13.1 Intended purpose control panel
The tool is conceptualised and designed exclusively for the
purpose of use specified here.
Scope of application:
Primary use for water and neutral, non-adhesive
liquids. Also suitable for air and neutral non-
flammable gases.
Maximum operating pressure (inlet pressure) 16
bar.
Outlet pressure infinitely adjustable from 1.5 to 6
bar.
Smallest possible inlet pressure 2.5 bar.
Minimum pressure drop (inlet pressure/outlet
pressure) 1 bar.
Maximum media and ambient temperature 75°C.
Assembly position as desired, preferable vertical.
13.2 Intended purpose solenoid valve
Scope of application:
Solenoid valves for liquid and gaseous media,
aggressive or neutral, can be used different
temperature and pressure ranges
Type 6213 is a 2/2 way solenoid valve with straight
passage, normally closed, with a permanently
coupled membrane system. It operates from 0 bar
and can be used universally for liquids. A minimum
pressure differential of 0.5 bar is required for the
valve to fully open.
13.3 Intended purpose flow meter
Scope of application:
The flow meter is used for the volume
measurement of transparent liquid and gaseous
flows in closed pipelines. Optionally the devices
can be used for flow monitoring.
