7
Chapter 1: Introduction
TTL Pulse (Rising/Falling Edge), Switch Closure
IRIG-B In (Modulated/Unmodulated)
Ready
F-Sync
Time Code Out: IRIG-B, SMPTE
Strobe
The two HD-SDI ports can acts as identical 4:2:2
HD-SDI ports with one set up to provide an optional)
on-screen display to monitor the on-camera controls
and cameaa operation. Or, they can be configured as a
‘single 4:4:4 Dual-Link HD-SDI port.
Off / Auto / On
Used to stamp images with acquisition data (azimuth
and elevation)
GPS input for GPS timing, longitude & latitude
RS-232 and Power (for Phantom Remote Control)
CAT5 UTP (for control and data transfer)
RJ45 10Base-T UTP (for control and data transfer)
20 - 28 Volts DC
20 - 28 Volts DC Backup
Ready, Strobe, A-Sync, Pre-trigger, NTSC/PAL Video
Trigger
Time Code In
I/O 1
I/O 2
I/O 3
I/O 4
HD-SDI 2
HD-SDI 1
Power Switch
Range Data
GPS
Remote Control Port
1 Gb Ethernet
10 Gb Ethernet
Primary DC Input
Backup DC Power
Capture Port
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
