Phantom Ultrahigh-speed Camera Manual
The UHS-12 Series are similar to the UHS-11 Series,
except for two differences. The first difference is the
increase in memory. The UHS-12 Series can be equipped
with either 72GB, 144GB, or 288GB of RAM. The second
difference is that the UHS-12 Series take advantage of
the CineMag IV, with 1TB or 2TB of non-volatile memory.
These enhancements are designed to make capturing,
accessing, and managing your critical data much easier.
The UHS-12 Cameras have the same excellent sensitivity
and framerates as the UHS-11 cameras, with the same
Phantom Features and outstanding image quality you’ve
come to expect from Phantom digital high-speed cameras.
Yes, a copper UTP 10Gb Ethernet interface is standard
on the camera. When properly configured, this allows for
cine downloads at speed up to 4 or 5 times that of the
Gb Ethernet interface. While any compatible 10GBASE-T
interface card installed in a PC should work, we have been
using and testing the interface with the Intel X540-T1 and
X540-T2 cards and find them to be very reliable.
Vision Research provides a ruggedized connector carrier
to be used when connecting a standard CAT6 or CAT6A
Ethernet cable between the camera and the interface
card. The customer must supply the appropriate cable.
A CAT6A cable is recommended and gives you a
maximum 100m distance between the camera and the
interface card. (A CAT6 cable is limited to 50m.)
Additional information is available in a Phantom Note
named “10Gb Ethernet Solutions for Phantom
Cameras and Accessories” and can be found at:
http://www.visionresearch.com/Service--Support/
Downloads/Documents/Technical-Notes/
Yes. In fact, there is a viewfinder port on the camera that
will supply video and power to a viewfinder or monitor. All
UHS-12 digital cameras come with a 280W power supply,
providing ample power for a camera with maximum
288GB memory, a 2TB CineMag, and the viewfinder
What is the
difference between
the Phantom UHS-12
Series (v2512, v2012,
v1612, and v1212) and
the previous UHS-11
Series (v2511, v2011,
v1611, and v1211)?
faqs
The v2512, v2012, v1612,
and v1212 all have
10Gb Ethernet interface.
Tell me more about it
and how to use it.
Can I use a viewfinder with
the Phantom v2512,
v2012, v1612, or v1212?
