30
䋼Condition
s
䋾
A
mbient tem
p
erature: 20/30㷄
Load: Unloaded
䋼Distribution dat
a
䋾
Temperature of the cycle in each area (SV=-80㷄䇮air temperature)
Unit:㷄
Maximum Minimum
Middle of
cycle
Differential Maximum Minimum
Middle of
cycle
Differential
㽲
-78.8 -84.7 -82.0 ±3.0 -78.8 -84.7 -82.0 ±3.0
㽳 -79.5 -84.8 -82.2 ±2.7 -79.5 -84.8 -82.2 ±2.7
㽴
-78.0 -84.9 -81.5 ±3.5 -78.0 -84.9 -81.5 ±3.5
㽵
-79.7 -84.5 -82.1 ±2.4 -79.7 -84.5 -82.1 ±2.4
㽶
-78.1
-81.4 -79.8 ±1.7 -78.1 -81.4 -79.8 ±1.7
㽷
-80.4 -83.4 -81.9 ±1.5 -80.4 -83.4 -81.9 ±1.5
㽸
-80.4 -83.3 -81.9 ±1.5 -80.4 -83.3 -81.9 ±1.5
㽹
-80.1 -83.2 -81.7 ±1.6 -80.1 -83.2 -81.7 ±1.6
㽺
-79.8 -82.9 -81.4 ±1.6 -79.8 -82.9 -81.4 ±1.6
㽻
-78.8
-81.3 -80.1 ±1.3 -78.8 -81.3 -80.1 ±1.3
㽼
-79.8 -82.8 -81.3 ±1.5 -79.8 -82.8 -81.3 ±1.5
㽽
-79.6 -82.5 -81.1 ±1.5 -79.6 -82.5 -81.1 ±1.5
㽾
-78.8 -81.1 -80.0 ±1.2 -78.8 -81.1 -80.0 ±1.2
㽿
-79.4 -82.0 -80.7 ±1.3 -79.4 -82.0 -80.7 ±1.3
㾀
-78.8 -81.1 -80.0 ±1.2 -78.8 -81.1 -80.0 ±1.2
Average - - -81.1 - - - -81.1 -
Unit:㷄
Maximum Minimum
Middle of
cycle
Differential Maximum Minimum
Middle of
cycle
Differential
㽲
-78.5 -84.4 -82.1 ±3.0 -79.2 -84.9 -82.4 ±2.9
㽳
-79.1 -84.5 -81.8 ±2.7 -79.8 -85.0 -82.4 ±2.6
㽴
-78.1 -84.6 -81.4 ±3.3 -78.6 -85.1 -81.9 ±3.3
㽵
-79.3 -84.4 -81.9 ±2.6 -80.0 -84.7 -82.4 ±2.4
㽶
-77.7
-81.3 -79.5 ±1.8 -78.4 -81.6 -80.0 ±1.6
㽷
-79.7 -83.4 -81.6 ±1.9 -80.5 -83.7 -82.1 ±1.6
㽸
-79.7 -83.3 -81.5 ±1.8 -80.6 -83.6 -82.1 ±1.5
㽹
-79.5 -83.2 -81.4 ±1.9 -80.3 -83.5 -81.9 ±1.6
㽺
-79.3 -82.9 -81.1 ±1.8 -80.1 -83.2 -81.7 ±1.6
㽻
-78.3
-81.2 -79.8 ±1.5 -79.0 -81.5 -80.3 ±1.3
㽼
-79.3 -82.7 -81.0 ±1.7 -80.2 -83.1 -81.7 ±1.5
㽽
-79.2 -82.5 -80.9 ±1.7 -80.0 -82.9 -81.5 ±1.5
㽾
-78.1 -81.1 -79.6 ±1.5 -78.9 -81.4 -80.2 ±1.3
㽿
-79.0 -81.9 -80.5 ±1.5 -79.7 -82.3 -81.0 ±1.3
㾀
-78.2 -80.9 -79.6 ±1.4 -78.9 -81.3 -80.1 ±1.2
Average - - -80.9 - - - -81.4 -
䋼
A
mount of power consumption䋾
A
mount of power consumption when driving at cycle
(
SV=-80㷄䋩
Uni
t
䋺kWh/da
y
50Hz 60Hz 50Hz 60Hz
115V - 4.07 - 4.89
220V - 4.27 - 5.11
230V 4.21 - 5.04 -
Note:This data does not represent a guarantee of product performance.
A
mbient temperature 30㷄
50Hz 60Hz
Ambient temperature 20㷄 Ambient temperature 30㷄
Note:This data does not represent a guarantee
of product performance.
A
mbient temperature 20㷄
50Hz 60Hz
