Cooling unit parts
<MDF-C8V1> for HITACHI compressor
Item
Specifications
Compressor
110/115V, 60Hz
Type: RL4588-P1 Compressor code: 7FB-0-M101-020-02
220V, 60Hz
Type: RL4588-R1 Compressor code: 7FB-0-M101-020-04
220/230/240V, 50Hz
Type: RL4588-S1 Compressor code: 7FB-0-M101-020-03
Refrigerant oil
Ze-NIUSL22SA Charged q’ty: 280cc
Cooling system
Forced air cooling
Condenser
Type
Finless tube
Cascade condenser
Condenser
8 columns x 2 lines
Coil pipe W200 mm x 12 columns
Pre-condenser
7 columns x 1 line P290 mm
―
Frame pipe
φ4.76 x T0.7 mm
―
Evaporator
Type
φ7.94 x T0.7 mm
Tube on sheet (also used as interior)
Capillary tube
Resistance (PSI kg/cm
2
)
6 kg/cm
2
Length (mm)
2000
Outer diameter (mm)
φ1.8
Refrigerant
HFC mixed refrigerant: MU-N49A(DOT)
Charged q’ty : 315 g
Oil additive
n-Pentane
Charged-q’ty : 10 g
Dryer
4A-XH-6
Charged q’ty : 58 g
Condensing fan
φ196 mm, 4 blades
Material: ABS
Condensing fan motor
(110/115V, 60Hz) SE4-D041N1P Output: 4W
(220/230/240V, 50Hz) SE4-D041N5P Output: 4W
