Phenix Technologies PM15-2 User Manual

5-1
PM15-2/PM15-4 PARTS LIST
Qty.
Phenix
Stock #
Item
Description
Mfg./Part Number
9109080
PM15-2 Complete Assembly
9109081
PM15-4 Complete Assembly
MECHANICAL
1
2100513
CASE
Case, Carrying, HD Polyethylene
Gemini GHO815RP-2,
Phenix Custom
1
40400030
PANEL
Panel, Divider, Chassis/Case
Phenix
1
40400031
BRACKET
Bracket, Front Panel to H.V. Panel
Phenix
1
N.P.N.
BRACKET
Bracket, Fiberglass Channel, Power Supply
Phenix
1
N.P.N.
PANEL
Panel, Fiberglass, H.V.
Phenix
1
42000014
PANEL
Panel, Front, Control/Metering
Phenix
CABLES/LEADS
1
1077170
CORD
Cord, Input Power, Right Angle
Newark 37F3354
*1
30070002
CABLE
Cable, H.V. Output, w/Insulated Clip
(RG58C/U)
1
30080004
LEAD
Lead, Return Test (Red) w/Insulated Clip
1
30080005
LEAD
Lead, Ground (Black), w/Insulated Clip
HIGH VOLTAGE COMPONENTS
1
1748200
R37
Resistor, 6W, 75M
EBG
1
1590171
H.V. POWER
SUPPLY
Power Supply, 15kV-2mA (PM15-2)
Ultravolt 15A24-N30-E-
T0B6
1
1590174
H.V. POWER
SUPPLY
Power Supply, 15kV-4mA (PM15-4)
Ultravolt 15C24-N60-E-
T0B6
ELECTRICAL PARTS/COMPONENTS
1
1152590
Module, Power Entry – Corcom 6VM1
Newark
4
1350104
Spacer/Standoff, 6-32X1/2"
Newark 67F4119
1
1351100
BINDING POST
Binding Post, Ground, Black
1
1351102
BINDING POST
Binding Post, Return, Red
*2
1603702
F1, A&B
Fuse, 2A, GDC
Newark 216.200
*3
1420145
LAMP
Lamp, Guard, High Voltage, Power, 28V
EAO 31-963.2
1
1422150
LENS-RED
Lens, Red, High Voltage Lamp
EAO 31-903.2
1
1422151
LENS-GREEN
Lens, Green, Power On Lamp
EAO 31-903.5
1
1422152
LENS-YELLOW
Lens, Yellow, Guard Lamp
EAO 31-903.4
*2
1501012
M1,M2
Voltmeter, Currentmeter, 50A, 3 ½”
Modutec T3S-DUA-050
1
N.P.N.
M1
Scale, Currentmeter
Phenix
1
N.P.N.
M2
Scale, Voltmeter
Phenix
1
1590170
POWER SUPPLY
24V
Power Supply, 24VDC, 2.5A
PSA-60-124
Phihong
1
1761092
R32
Linear Pot., 10K, 1 Turn - Current Trip
Mouser 31VA401
1
1355305
R32 KNOB
Knob for Current Trip Pot.
1
1761960
R36
100k Linear Pot w/Switch – Voltage Control
Farnell 106-478
