76
107T6 CRT
21
GENERAL PRODUCT SPECIFICATION
B-3 Transportation standards
(Test conditions: ambient temperature 20-23degreeC, relative humidity 40 - 65%)
Standards
PCE All Regions Except C hina & India
PCE Standard
PCE China & India
PCE Standard
Vibration test
Sequence 7Hz, 1.05G a.10-30-10Hz. Amplitude: 19mm
Amplitude(peak to peak): 10.6mm Sweep: 5, Duration: 15min.
Duration: 30 min. 3 axes (Refer to GB9384-97)
1 axes (transport direction) b. 30-55-10Hz. Amplitude: 6mm
Sweep: 5, Duration: 9min
3axes(Refer to GB9384-97)
Result Electrical function OK.
- Mechanical function OK.
- No serious damage in set
Parameter No Acceleration: 100m/s2,
Pulse duration: 16ms,
Bump Number of pulses: 1000,
test Bump frequency:60-80 times/min.
(Refer to GB9384-97)
Result - Electrical function OK.
- Mechanical function OK.
- No serious damage in set
Height 42/25cm(weight:15-16kg ) 60/50 cm (weight:10-19kg )
Sequence Bottom(3 times): 42cm, 6 face(bottom-front-left-rear-right)
Left/Front/Right/Rear/Top: 25cm 3 edge( front-bot, right-bot, front-right)
Drop test
( cold drop test: when applicable,
perform also the drop test with new
packaging after pre-condition for
Face : 60cm
(colddrop
16 hours at -10
C)
Edge/Corner: 50 cm
test) ( cold drop test: pre-condition for
16 hours at -10 C)
Result - Electrical function OK.
- Mechanical function OK.
- No serious damage in set
For design evaluation only.
Shock Half sine shock : 100G,<3msec.6 shocks
test Temp.
: 23
C
Humidity : 60%
Air pressure :100kpa
Standard : Mechanical Guideline
Go to cover page
8639 000 15483
BRAND : PHILIPS
17" V32GS4 107T6-71K CMTR
TYPE :107T60/00
2004-04-16
2004-04-16
31
Wayn e Lin
