ELECTRICAL PARTS LIST
Pos.
12 NC Description
14PV365/58
14PV360/39
14PV365/01
14PV365/07
14PV365/39
14PV360/01
14PV360/07
C859 CERAMIC CAP.(AX) SL J 33PF/50V 1111111
C860 ELECTROLYTIC CAP. 10UF/25V M H7 1111111
C861 CERAMIC CAP.(AX) Y M 0.01UF/16V 1111111
C862 ELECTROLYTIC CAP. 33UF/10V H7 1111111
C863 ELECTROLYTIC CAP. 1UF/50V M H7 1111111
C864 CERAMIC CAP.(AX) Y N 0.022UF/6V 1111111
C865 ELECTROLYTIC CAP. 4.7UF/50V M H7 1111111
C866 ELECTROLYTIC CAP. 1UF/50V M H7 1111111
C867 ELECTROLYTIC CAP. 1UF/50V M H7 1111111
C868 ELECTROLYTIC CAP. 1UF/50V M H7 1111111
C869 ELECTROLYTIC CAP. 1UF/50V M H7 1111111
C870 CERAMIC CAP.(AX) Y M 0.01UF/16V 1111111
C871 ELECTROLYTIC CAP. 47UF/6.3V M H7 1111111
C872 CERAMIC CAP.(AX) B K 150PF/50V 1111111
C873 CERAMIC CAP.(AX) B K 150PF/50V 1111111
C874 CERAMIC CAP.(AX) B K 220PF/50V 1111111
C875 CERAMIC CAP.(AX) X M 4700PF/16V 1111111
C876 CERAMIC CAP.(AX) Y N 0.022UF/6V 1111111
C877 CERAMIC CAP.(AX) Y N 0.022UF/6V 1111111
MISCELLANEOUS
CF101 9965 000 13835 CERAMIC RESONATOR 4.433MHZ 1111111
CL301A 9965 000 13836 LEAD WIRE 4P/300 1111111
CL302A 9965 000 13837 LEAD WIRE 7P/230 1111111
CL603A 9965 000 13838 LEAD WIRE 15P(7+8)/330 1111111
CL702A 9965 000 13839 WIRE 140/BRO/AWG18#1007 1111111
1005 2422 542 90129 TUN SPLIF V+U PLL IEC BGDKI B 1 1 1 1 1
1005 2422 542 90132 TUN SPLIF V+U PLL IEC BGDKIL B 1 1
1006 2422 542 90133 TUN IF V+U PLL IEC BGDKIL B 1 1
1006 2422 542 90128 TUN IF V+U PLL IEC BGDKI B 1 1 1 1 1
1100 CRT A34EAC01X71 (PHCO) B 1111111
5000 3143 021 00011 DEG COIL FUNAI 1111111
8000 3143 021 00031 EARTH CABLE 1111111
8016 2422 070 98211 MAINSCORD EUR 2A5 1M7 BK B 1 1 1 1 1
8016 2422 070 98218 MAINSCORD UK 5A 1M8 BK B 1 1
8200 3143 021 00021 TUNER CABLE 1111111
CONNECTORS
CN201 9965 000 13840 FFC/FPC CONNECTOR 12P 04 6232 112 103 800 1111111
CN303 9965 000 13841 CONNECTOR BASE, 5P TUC-P05P-B1 1111111
CN701 9965 000 05247 CONNECTOR BASE 4P TUC-P04P-B1 1111111
CN702 9965 000 05247 CONNECTOR BASE 4P TUC-P04P-B1 1111111
CN751 9965 000 13842 CONNECTOR BASE 8P TUC-P08P-B1 1111111
CN752 9965 000 13843 CONNECTOR BASE, 6P TUC-P06P-B1 1111111
CN801 9965 000 13844 STRAIGHT CONNECTOR BASE 00 8283 0212 00 000 1111111
DIODES
D201 9965 000 05250 LED SIR-563ST3F P 1111111
D203 9965 000 13846 LED(RED) L-1513EC 1111111
D206 9965 000 05249 ZENER DIODE MTZJT-775.6B 1111111
D207 9965 000 05249 ZENER DIODE MTZJT-775.6B 1111111
D208 9965 000 13847 DIODE 1N5397-B 1111111
D210 4822 130 83166 ZENER DIODE MTZJT-776.2B 1111111
D211 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D212 PCB JUMPER D0.6-P5.0 1111111
D213 4822 130 83166 ZENER DIODE MTZJT-776.2B 1111111
D214 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D215 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D216 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D217 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D218 9965 000 05249 ZENER DIODE MTZJT-775.6B 1111111
D301 9965 000 11153 ZENER DIODE MTZJT-778.2B 1111111
D304 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D305 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D306 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
