Philips 14PV360 - Page 56

ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
14PV365/58 14PV360/39 14PV365/01 14PV365/07 14PV365/39 14PV360/01 14PV360/07
D307 9965 000 11153 ZENER DIODE MTZJT-778.2B 1111111
D309 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D312 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D401 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D402 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D471 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1 1
D680 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D681 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D682 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D683 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D684 9965 000 05249 ZENER DIODE MTZJT-775.6B 1111111
D685 4822 130 11629 ZENER DIODE MTZJT-776.8B 1111111
D686 9965 000 13847 DIODE 1N5397-B 1111111
D702 4822 130 83166 ZENER DIODE MTZJT-776.2B 1111111
D751 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D752 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D754 9965 000 12904 ZENER DIODE DZ-5.1BSBT265 1111111
D755 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D757 4822 130 83166 ZENER DIODE MTZJT-776.2B 1111111
D758 4822 130 83166 ZENER DIODE MTZJT-776.2B 1111111
D759 4822 130 83166 ZENER DIODE MTZJT-776.2B 1111111
D760 9965 000 05249 ZENER DIODE MTZJT-775.6B 1111111
D761 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D762 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D763 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D764 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D801 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D802 PCB JUMPER D0.6-P5.0 1111111
D804 9965 000 13848 ZENER DIODE MTZJT-777.5B 1111111
D805 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
D806 4822 130 32778 SWITCHING DIODE 1SS133(T-77) 1111111
IC’s
IC101 9965 000 13926 IC/VPS,PDC LC74793 1111111
IC201 9965 000 13849 MICRO COMPUTER M37760MFH7B7GP 1111111
IC202 9965 000 13030 IC:MEMORY BR24C04F-W 1111111
IC301 9965 000 13850 IC:CHROMA/IF 1 CHIP M61209FP-R609 1111111
IC401 9965 000 12180 IC:Y/C/A LA71750AM-MTB 1111111
IC471 9965 000 13927 IC:SECAM LA70100M-MPB 1 1
IC602 9965 000 13851 VOLTAGE REGULATOR KIA7805API 1111111
IC751 9965 000 13852 IC:SWITCH TC4053BF(N) 1111111
IC752 9965 000 13852 IC:SWITCH TC4053BF(N) 1111111
IC754 9965 000 13852 IC:SWITCH TC4053BF(N) 1111111
IC801 9965 000 13853 AUDIO AMP LA4224 1111111
RCA JACK
JK701 4822 265 11659 RCA JACK(YELLOW) MSP-281V4-B 1111111
JK702 4822 265 11661 RCA JACK(WHITE) MSP-281V1-B 1111111
JK751 9965 000 13854 SKIRT JACK 21P HRC-21V-02P 1111111
JK801 9965 000 13855 HEADPHONE JACK MSJ-035-10A B 1111111
COILS
L001 4822 157 10326 INDUCTOR 10UH-K-5FT 1111111
L002 9965 000 13856 INDUCTOR 1.0UH-J-26T 1111111
L003 9965 000 13856 INDUCTOR 1.0UH-J-26T 1111111
L101 PCB JUMPER D0.6-P5.0 1111111
L201 9965 000 05627 CHOKE COIL 47UH-K 1111111
L202 9965 000 13857 INDUCTOR 0.10UH-K-26T 1111111
L203 9965 000 05627 CHOKE COIL 47UH-K 1111111
L301 9965 000 05627 CHOKE COIL 47UH-K 1111111
L302 9965 000 13858 INDUCTOR 33UH-J-26T 1111111
L303 9965 000 13858 INDUCTOR 33UH-J-26T 1111111
L304 PCB JUMPER D0.6-P5.0 1111111
L401 9965 000 13859 INDUCTOR 22UH-J-26T 1111111
L403 9965 000 13858 INDUCTOR 33UH-J-26T 1111111
1-14-6
