ELECTRICAL PARTS LIST
Pos.
12 NC Description
14PV365/58
14PV360/39
14PV365/01
14PV365/07
14PV365/39
14PV360/01
14PV360/07
L485 PCB JUMPER D0.6-P5.0 1 1
L751 9965 000 13860 INDUCTOR 12UH-J-26T 1111111
L752 9965 000 13861 INDUCTOR 1.2UH-J-26T 1111111
L801 9965 000 13856 INDUCTOR 1.0UH-J-26T 1111111
L851 PCB JUMPER D0.6-P5.0 1111111
L852 9965 000 05705 INDUCTOR 47UH-K-5FT 1111111
L853 PCB JUMPER D0.6-P5.0 1111111
L854 PCB JUMPER D0.6-P5.0 1111111
L856 PCB JUMPER D0.6-P5.0 1111111
TRANSISTORS
PI201 9965 000 12189 PHOTO INTERRUPTER RPI-302C70 1111111
Q205 9965 000 13862 TRANSISTOR 2SB892(S) 1111111
Q206 9965 000 08630 PHOTO TRANSISTOR PT204-6B-12 1111111
Q207 4822 130 10098 RES. BUILT-IN TRANSISTOR KRC103M 1111111
Q208 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q401 4822 130 42959 TRANSISTOR KTA1266(GR) 1111111
Q402 4822 130 11101 TRANSISTOR 2SA1015-GR(TPE2) 1111111
Q471 9965 000 05643 TRANSISTOR 2SC2785(F) 1 1
Q680 4822 130 42292 TRANSISTOR 2SC2120-Y(TPE2) 1111111
Q681 9965 000 13863 TRANSISTOR 2SD1913(R) 1111111
Q682 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q751 4822 130 11101 TRANSISTOR 2SA1015-GR(TPE2) 1111111
Q752 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q753 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q754 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q755 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q756 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q757 4822 130 11101 TRANSISTOR 2SA1015-GR(TPE2) 1111111
Q758 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q759 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q760 4822 130 10145 RES. BUILT-IN TRANSISTOR KRA103M 1111111
Q761 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q851 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
Q852 4822 130 11101 TRANSISTOR 2SA1015-GR(TPE2) 1111111
Q853 4822 130 42292 TRANSISTOR 2SC2120-Y(TPE2) 1111111
Q854 4822 130 10097 TRANSISTOR 2SC3331(T) 1111111
Q855 4822 130 10097 TRANSISTOR 2SC3331(T) 1111111
Q856 4822 130 10145 RES. BUILT-IN TRANSISTOR KRA103M 1111111
Q857 9965 000 05643 TRANSISTOR 2SC2785(F) 1111111
RESISTORS
R002 CARBON RES. 1/4W J 22K OHM 1111111
R102 CARBON RES. 1/4W J 10K OHM 1111111
R103 CARBON RES. 1/4W J 2.7K OHM 1111111
R104 CARBON RES. 1/4W J 5.6K OHM 1111111
R105 CARBON RES. 1/4W J 10K OHM 1111111
R106 CARBON RES. 1/4W J 100 OHM 1111111
R107 CARBON RES. 1/4W J 10K OHM 1111111
R201 CARBON RES. 1/4W J 22K OHM 1111111
R202 CARBON RES. 1/4W J 22K OHM 1111111
R203 PCB JUMPER D0.6-P5.0 1111111
R204 CARBON RES. 1/4W J 390K OHM 1111111
R205 CARBON RES. 1/4W J 10K OHM 1111111
R206 CARBON RES. 1/4W J 1.5K OHM 1111111
R207 CARBON RES. 1/4W J 1.5K OHM 1111111
R208 CARBON RES. 1/4W J 2.2K OHM 1111111
R209 CARBON RES. 1/4W J 2.7K OHM 1111111
R210 CARBON RES. 1/4W J 10K OHM 1111111
R211 CARBON RES. 1/4W J 1.5K OHM 1111111
R212 CARBON RES. 1/4W J 1.5K OHM 1111111
R213 CARBON RES. 1/4W J 2.2K OHM 1111111
R214 CARBON RES. 1/4W J 2.7K OHM 1111111
R215 CARBON RES. 1/4W G 4.7K OHM 1111111
To Next Page
