49
170S6 LCD
General Product Specification
8639 000 16148
2004-12-15
590
7
26
Peter.V
202P Gs3 CM25
17 inch LCD Monitor
TYPE : 170S6FG/00
BRAND : PHILIPS
2004-12-15
3.0Electrical characteristics
3.1Interfacesignals
1). D-shell Analog
Input signal: Video, H-sync,V-sync,
Video: 0.7 Vp-p, inputimpedance, 75 ohm
Sync. :Separatesync :TTL level, inputimpedance 2k2ohm term
inate
H-sync :Positive/Negative
V-sync :Positive/Negative
Compositesync :TTL level, inputimpedance 2k2ohm t erminate
(Positive/Negative)
Sync on green video:0.3V p-p Negative. (Video0.7 Vp-p Positive)
3.2Interface
3.2.1D-S
ub Cable
Length. :1.8 M +/- 50 mm
Connector type. :D-Sub male with DDC-2B pin assignments.
Blue connector thumb-operated jackscrews
Pin Assignment:
PIN No. SIGNAL
1Red videoinput
2Green videoinput/sync on green
3 Blue videoinput
4GND
5 GND- Cable detect
6Red videoGND
7Green videoGND
8 Blue videoGND
9 DDC +3.3V or +5V
10 Logic GND
11 GND
12 Serial dataline(SDA)
13 H-sync / H+V
14 V-sync
15 Data clockline(SCL)
