Philips 150S6FB/27 - Spare Parts List

To Next Page

To Previous Page

170S6 LCD

Spare Parts List - 170S6

Model: 170S6FG/00(QDI)

Mechanical Parts

0030 313815756091 BEZEL ASSY(T)

0031 313815412032 BEZEL(T)

0032 313815412731 POWER BUTTON

0033 313815412711 CONTROL BUTTON

0034 313815411561 POWER LENS

0040 313815759391 BACK COVER ASSY

0041 313815412043 BACK COVER

0042 313815135321 HINGE-PLATE

0050 313815756112 FOLDABLE BASE(T)

0090 313810440571 HOUSING COVER

0100 313815136741 SHIELDING-LPL

0101 313815411831 HINGE COVER(T)

Packing Materials

0450 313815639311 CARTON

0453 313815621491 P.E. BAG

0451 313815639811 CUSHION-R

0452 313815639801 CUSHION-L

Accessaries

0602 313811708271 E-D.F.U.

1158 313819871192 CORD SUB-D 15/1M8/SUB-D 15GY

1157 313817874701 MAIN CORD (1.5M. EUROPEAN)

LCD Panel

1050 823827717631 TFT-LCD MOD QD170EL07 REV.09

PCB ASSY

1051 313815862681 SCALER ASSY

1052 823827717131 LIPS(EADP-43AF A)

1053 313815861661 CONTROL ASSY

Others

0291 313815566231 LABEL-CPU

0295 313815566241 LABEL-EEPROM(Q)

0615 313811708131 HEX CODE OF F/W(NO MATL REQ)

1160 313815862741 METAL FRAME+WIRE ASSY

1201 242202518065 SOC SUBD H 15P F BU 900 Y

1302 243854300079 RES XTL SM 12MHZ 32P SMD-49 R

1341 243803100435 SOC IC V 8P F 2.54 DIL L

1451 242202519002 CON H 30P F 1.00 SM FFC 0.3 R

1501 242202518824 CON V 11P M 2.00 63391 B

1512 242202518999 CON V 7P M 2.00 61387 B

1901 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1902 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1903 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1904 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1905 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1906 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1907 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1910 242202518897 CON H 7P M 2.00 63367 B

8161 313819874621 CBLE-427 7/240/7-427 AWG28

8163 313819874611 FFC 30/185/30 PITCH 1.0MM

1051 313815862681 SCALER ASSY

2202 223886715339 CER1 0603 NP0 50V 33P PM5 R

2203 223886715221 CER1 0603 NP0 50V 220P PM5 R

2207 223878615649 CER2 0603 X7R 16V 100N PM10 R

2210 223878615649 CER2 0603 X7R 16V 100N PM10 R

2211 223878615649 CER2 0603 X7R 16V 100N PM10 R

2213 223878615649 CER2 0603 X7R 16V 100N PM10 R

2214 223878615649 CER2 0603 X7R 16V 100N PM10 R

2215 223878615649 CER2 0603 X7R 16V 100N PM10 R

2216 223878615649 CER2 0603 X7R 16V 100N PM10 R

2217 223878615649 CER2 0603 X7R 16V 100N PM10 R

2219 223878615649 CER2 0603 X7R 16V 100N PM10 R

2301 223878615649 CER2 0603 X7R 16V 100N PM10 R

2302 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2303 223886715229 CER1 0603 NP0 50V 22P PM5 R

2304 223886715229 CER1 0603 NP0 50V 22P PM5 R

2305 223886715101 CER1 0603 NP0 50V 100P PM5 R

2307 223886715101 CER1 0603 NP0 50V 100P PM5 R

2308 223886715101 CER1 0603 NP0 50V 100P PM5 R

2322 223878615649 CER2 0603 X7R 16V 100N PM10 R

2341 223878615649 CER2 0603 X7R 16V 100N PM10 R

2412 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2413 223878615649 CER2 0603 X7R 16V 100N PM10 R

2415 202203100378 ELCAP RGA 6V3 S 680U PM20 A

2416 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2417 223878615649 CER2 0603 X7R 16V 100N PM10 R

2421 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2422 223878615649 CER2 0603 X7R 16V 100N PM10 R

2423 223878615649 CER2 0603 X7R 16V 100N PM10 R

2424 223878615649 CER2 0603 X7R 16V 100N PM10 R

2425 223878615649 CER2 0603 X7R 16V 100N PM10 R

2431 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2432 223878615649 CER2 0603 X7R 16V 100N PM10 R

2433 223878615649 CER2 0603 X7R 16V 100N PM10 R

2434 223878615649 CER2 0603 X7R 16V 100N PM10 R

2435 223878615649 CER2 0603 X7R 16V 100N PM10 R

2436 223878615649 CER2 0603 X7R 16V 100N PM10 R

2437 223878615649 CER2 0603 X7R 16V 100N PM10 R

2438 223878615649 CER2 0603 X7R 16V 100N PM10 R

2441 223878615649 CER2 0603 X7R 16V 100N PM10 R

2442 223878615649 CER2 0603 X7R 16V 100N PM10 R

2501 223878615649 CER2 0603 X7R 16V 100N PM10 R

2502 223878615649 CER2 0603 X7R 16V 100N PM10 R

2506 223878615649 CER2 0603 X7R 16V 100N PM10 R

2507 223878615649 CER2 0603 X7R 16V 100N PM10 R

2508 202203100216 ELCAP RGA 16V S 220U PM20 A

2513 223858615623 CER2 0603 X7R 50V 1N PM10 R

2514 223858615623 CER2 0603 X7R 50V 1N PM10 R

2515 223858615623 CER2 0603 X7R 50V 1N PM10 R

2516 223858615623 CER2 0603 X7R 50V 1N PM10 R

2517 223858615623 CER2 0603 X7R 50V 1N PM10 R

2534 223858615636 CER2 0603 X7R 50V 10N PM10 R

2536 203803527501 ELCAP KM 50V S 10U PM20 A

2537 223878615649 CER2 0603 X7R 16V 100N PM10 R

2541 223878615649 CER2 0603 X7R 16V 100N PM10 R

2542 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2543 202202000903 ELCAP SM 10V S 100U PM20 A

2544 223878615649 CER2 0603 X7R 16V 100N PM10 R

2545 223878615649 CER2 0603 X7R 16V 100N PM10 R

2546 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2547 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2548 223878615649 CER2 0603 X7R 16V 100N PM10 R

3201 232270260101 RST SM 0603 RC21 100R PM5 R

3202 232270260101 RST SM 0603 RC21 100R PM5 R

3203 232270260101 RST SM 0603 RC21 100R PM5 R

3204 232270260101 RST SM 0603 RC21 100R PM5 R

3205 232270260222 RST SM 0603 RC21 2K2 PM5 R

3206 232270260222 RST SM 0603 RC21 2K2 PM5 R

3207 232270260102 RST SM 0603 RC21 1K PM5 R

3210 232270260339 RST SM 0603 RC21 33R PM5 R

3211 232270260339 RST SM 0603 RC21 33R PM5 R

3212 232270467509 RST SM 0603 RC22H 75R PM1 R

3213 232270260519 RST SM 0603 RC21 51R PM5 R

3214 232270260339 RST SM 0603 RC21 33R PM5 R

3215 232270467509 RST SM 0603 RC22H 75R PM1 R

3216 232270260519 RST SM 0603 RC21 51R PM5 R

3217 232270260339 RST SM 0603 RC21 33R PM5 R

3218 232270467509 RST SM 0603 RC22H 75R PM1 R

3219 232270260519 RST SM 0603 RC21 51R PM5 R

3241 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3243 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3302 232270260105 RST SM 0603 RC21 1M PM5 R

3303 232270260101 RST SM 0603 RC21 100R PM5 R

3304 232270260101 RST SM 0603 RC21 100R PM5 R

3306 232270260473 RST SM 0603 RC21 47K PM5 R

3307 212211805669 RST SM 0603 RC0603 10K PM5 R

3308 232270260101 RST SM 0603 RC21 100R PM5 R

3309 232270260101 RST SM 0603 RC21 100R PM5 R

3310 232270260101 RST SM 0603 RC21 100R PM5 R

3311 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3312 232270260472 RST SM 0603 RC21 4K7 PM5 R

3313 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3314 232270260472 RST SM 0603 RC21 4K7 PM5 R

3320 232270260472 RST SM 0603 RC21 4K7 PM5 R

3322 212211805669 RST SM 0603 RC0603 10K PM5 R

3323 232270260101 RST SM 0603 RC21 100R PM5 R

3324 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3325 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3342 232270260472 RST SM 0603 RC21 4K7 PM5 R

3343 232270260472 RST SM 0603 RC21 4K7 PM5 R

3345 232270260101 RST SM 0603 RC21 100R PM5 R

3346 232270260101 RST SM 0603 RC21 100R PM5 R

3401 232270260101 RST SM 0603 RC21 100R PM5 R

3402 232270260101 RST SM 0603 RC21 100R PM5 R

3403 212211805637 RST SM 0603 RC0603 22R PM5 R

3404 212211805637 RST SM 0603 RC0603 22R PM5 R

3405 212211805637 RST SM 0603 RC0603 22R PM5 R

3406 232270260101 RST SM 0603 RC21 100R PM5 R

3407 232270260101 RST SM 0603 RC21 100R PM5 R

3408 212211805637 RST SM 0603 RC0603 22R PM5 R

3411 232270468201 RST SM 0603 RC22H 820R PM1 R

3412 232270462702 RST SM 0603 RC22H 2K7 PM1 R

3501 212211805639 RST SM 0603 RC0603 47R PM5 R

3502 212211805639 RST SM 0603 RC0603 47R PM5 R

3503 212211805639 RST SM 0603 RC0603 47R PM5 R

3513 232270260101 RST SM 0603 RC21 100R PM5 R

3514 232270260101 RST SM 0603 RC21 100R PM5 R

3515 232270260102 RST SM 0603 RC21 1K PM5 R

3516 212211805647 RST SM 0603 RC0603 220R PM5 R

3517 212211805647 RST SM 0603 RC0603 220R PM5 R

3518 212211805669 RST SM 0603 RC0603 10K PM5 R

3519 212211805669 RST SM 0603 RC0603 10K PM5 R

3521 212211805669 RST SM 0603 RC0603 10K PM5 R

3522 212211805669 RST SM 0603 RC0603 10K PM5 R

3523 212211805669 RST SM 0603 RC0603 10K PM5 R

3531 212211805972 RST SM 1206 JUMP. MAX 0R05 R

3533 232270260473 RST SM 0603 RC21 47K PM5 R

3534 232270260104 RST SM 0603 RC21 100K PM5 R

3535 212211805669 RST SM 0603 RC0603 10K PM5 R

5210 242254945579 IND FXD 1206 EMI 100MHZ 100R R

5415 242254900113 IND FXD 0603 EMI 100MHZ 1K R

5421 242254945579 IND FXD 1206 EMI 100MHZ 100R R

5431 242254945579 IND FXD 1206 EMI 100MHZ 100R R

5501 242254944196 IND FXD 0805 EMI 100MHZ 120R R

5502 242254944196 IND FXD 0805 EMI 100MHZ 120R R

5503 242254944196 IND FXD 0805 EMI 100MHZ 120R R

5507 242254945579 IND FXD 1206 EMI 100MHZ 100R R

5535 242254945579 IND FXD 1206 EMI 100MHZ 100R R

6201 933137390215 DIO REG SM BZX84-C5V1 (PHSE) R

6204 933137390215 DIO REG SM BZX84-C5V1 (PHSE) R

6205 933137390215 DIO REG SM BZX84-C5V1 (PHSE) R

6206 933137390215 DIO REG SM BZX84-C5V1 (PHSE) R

6301 932205042685 DIO SIG SM BAV99LG (ONSE) R

6302 932205042685 DIO SIG SM BAV99LG (ONSE) R

6303 933976370215 DIO SIG SM BAT54C (PHSE) R

7301 313815862711 CPU IC ASSY

7301 932220582682 IC SM NT68F633L (NOVA) L

7341 313815862721 EEPROM ASSY-QDI

7341 932218650682 IC AT24C16A-10PU-2.7 (ATME) L

7401 823827716531 NT68521AEF ANALAG SXGA SCALER

7518 932217439685 TRA SIG SM BC857C (KEC0) R

7519 932217439685 TRA SIG SM BC857C (KEC0) R

7531 932216638668 FET POW SM SI5441DC-E3 (VISH)R

7532 934036790115 TRA SIG SM PDTC114EK (PHSE) R

7541 932222077668 IC SM AME1117ECGTZ (ST00) R

7545 932222076668 IC SM AME1117CCGTZ (ST00) R

1053 313815861661 CONTROL ASSY

3902 232270260473 RST SM 0603 RC21 47K PM5 R

3903 212211805669 RST SM 0603 RC0603 10K PM5 R

3904 232270260102 RST SM 0603 RC21 1K PM5 R

3905 232270260473 RST SM 0603 RC21 47K PM5 R

3906 212211805669 RST SM 0603 RC0603 10K PM5 R

3907 232270260102 RST SM 0603 RC21 1K PM5 R

6910 932219981682 LED VS L-3WYGW-8.03* (KIEL) B
