Spare Parts List - 150S6

Model:150S6FG/00(LPL)

Mechanical Parts

0030 313815756071 BEZEL ASSY(T)

0031 313815411811 BEZEL(T)

0032 313815411781 BUTTON-POWER

0033 313815411771 FUNCTION KEYS

0034 313815411791 LENS

0040 313815759211 BACK COVER ASSY

0041 313815411822 BACK COVER

0042 313815040551 SQUARE NUT-M4

0043 313815759221 HINGE-PLATE ASSY

0044 313815135171 HINGE-PLATE

0050 313815756062 FOLDABLE BASE(T)

0090 313810440571 HOUSING COVER

0100 313815136951 SHIELDING INVENTER

0101 313815411831 HINGE COVER(T)

Packing Materials

0450 313815639561 CARTON

0451 313815639731 CUSHION-R

0452 313815639721 CUSHION-L

0453 313815621481 P.E.BAG

Accessaries

0602 313811708281 E-D.F.U

1157 313817874701 MAIN CORD (1.5M. EUROPEAN)

1158 313819871192 CORD SUB-D 15/1M8/SUB-D 15GY

LCD Panel

1050 823827716851 LCD LM150X08-A5

PCB ASSY

1051 313815862021 SCALER ASSY

1052 823827717281 LIPS(AIP-0097)

1053 313815861661 CONTROL ASSY

Others

0291 313815566271 LABEL-LG

0295 313815566271 LABEL-LG

0615 313811708071 HEX CODE OF F/W(LG)

1160 313815862061 METAL FRAME+WIRE ASSY

1201 242202518065 SOC SUBD H 15P F BU 900 Y

1302 243854300079 RES XTL SM 12MHZ 32P SMD-49 R

1341 243803100435 SOC IC V 8P F 2.54 DIL L

1452 242202505567 CON V 20P M 1.25 SM 60947 R

1501 242202518824 CON V 11P M 2.00 63391 B

1512 242202518999 CON V 7P M 2.00 61387 B

1901 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1902 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1903 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1904 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1905 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1906 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1907 242212803007 SWI TACT 1P 1POS 12V V 5MM B

1910 242202518897 CON H 7P M 2.00 63367 B

8161 313819871201 CBLE-207 7/160/7-207 AWG28

8163 313819874951 CBLE -104 20/95/20-032 AWG

1051 313815862021 SCALER ASSY

2202 223886715339 CER1 0603 NP0 50V 33P PM5 R

2203 223886715221 CER1 0603 NP0 50V 220P PM5 R

2207 223878615649 CER2 0603 X7R 16V 100N PM10 R

2210 223878615649 CER2 0603 X7R 16V 100N PM10 R

2211 223878615649 CER2 0603 X7R 16V 100N PM10 R

2213 223878615649 CER2 0603 X7R 16V 100N PM10 R

2214 223878615649 CER2 0603 X7R 16V 100N PM10 R

2215 223878615649 CER2 0603 X7R 16V 100N PM10 R

2216 223878615649 CER2 0603 X7R 16V 100N PM10 R

2217 223878615649 CER2 0603 X7R 16V 100N PM10 R

2219 223878615649 CER2 0603 X7R 16V 100N PM10 R

2301 223878615649 CER2 0603 X7R 16V 100N PM10 R

2302 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2303 223886715229 CER1 0603 NP0 50V 22P PM5 R

2304 223886715229 CER1 0603 NP0 50V 22P PM5 R

2305 223886715101 CER1 0603 NP0 50V 100P PM5 R

2307 223886715101 CER1 0603 NP0 50V 100P PM5 R

2308 223886715101 CER1 0603 NP0 50V 100P PM5 R

2322 223878615649 CER2 0603 X7R 16V 100N PM10 R

2341 223878615649 CER2 0603 X7R 16V 100N PM10 R

2412 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2413 223878615649 CER2 0603 X7R 16V 100N PM10 R

2415 202203100378 ELCAP RGA 6V3 S 680U PM20 A

2416 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2417 223878615649 CER2 0603 X7R 16V 100N PM10 R

2421 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2422 223878615649 CER2 0603 X7R 16V 100N PM10 R

2423 223878615649 CER2 0603 X7R 16V 100N PM10 R

2424 223878615649 CER2 0603 X7R 16V 100N PM10 R

2425 223878615649 CER2 0603 X7R 16V 100N PM10 R

2431 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2432 223878615649 CER2 0603 X7R 16V 100N PM10 R

2433 223878615649 CER2 0603 X7R 16V 100N PM10 R

2434 223878615649 CER2 0603 X7R 16V 100N PM10 R

2435 223878615649 CER2 0603 X7R 16V 100N PM10 R

2436 223878615649 CER2 0603 X7R 16V 100N PM10 R

2437 223878615649 CER2 0603 X7R 16V 100N PM10 R

2438 223878615649 CER2 0603 X7R 16V 100N PM10 R

2441 223878615649 CER2 0603 X7R 16V 100N PM10 R

2442 223878615649 CER2 0603 X7R 16V 100N PM10 R

2501 223878615649 CER2 0603 X7R 16V 100N PM10 R

2502 223878615649 CER2 0603 X7R 16V 100N PM10 R

2506 223878615649 CER2 0603 X7R 16V 100N PM10 R

2507 223878615649 CER2 0603 X7R 16V 100N PM10 R

2508 203803527203 ELCAP KM 16V S 220U PM20 A

2513 223858615623 CER2 0603 X7R 50V 1N PM10 R

2514 223858615623 CER2 0603 X7R 50V 1N PM10 R

2515 223858615623 CER2 0603 X7R 50V 1N PM10 R

2516 223858615623 CER2 0603 X7R 50V 1N PM10 R

2517 223858615623 CER2 0603 X7R 50V 1N PM10 R

2534 223858615636 CER2 0603 X7R 50V 10N PM10 R

2536 203803527501 ELCAP KM 50V S 10U PM20 A

2537 223878615649 CER2 0603 X7R 16V 100N PM10 R

2541 223878615649 CER2 0603 X7R 16V 100N PM10 R

2542 222224119876 CER2 1206 Y5V 10V 10U P8020 R

2543 202202000903 ELCAP SM 10V S 100U PM20 A

2544 223878615649 CER2 0603 X7R 16V 100N PM10 R

3201 232270260101 RST SM 0603 RC21 100R PM5 R

3202 232270260101 RST SM 0603 RC21 100R PM5 R

3203 232270260101 RST SM 0603 RC21 100R PM5 R

3204 232270260101 RST SM 0603 RC21 100R PM5 R

3205 232270260222 RST SM 0603 RC21 2K2 PM5 R

3206 232270260222 RST SM 0603 RC21 2K2 PM5 R

3207 232270260102 RST SM 0603 RC21 1K PM5 R

3210 232270260339 RST SM 0603 RC21 33R PM5 R

3211 232270260339 RST SM 0603 RC21 33R PM5 R

3212 232270467509 RST SM 0603 RC22H 75R PM1 R

3213 232270260519 RST SM 0603 RC21 51R PM5 R

3214 232270260339 RST SM 0603 RC21 33R PM5 R

3215 232270467509 RST SM 0603 RC22H 75R PM1 R

3216 232270260519 RST SM 0603 RC21 51R PM5 R

3217 232270260339 RST SM 0603 RC21 33R PM5 R

3218 232270467509 RST SM 0603 RC22H 75R PM1 R

3219 232270260519 RST SM 0603 RC21 51R PM5 R

3241 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3243 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3301 213811291002 RST SM 0805 JUMP. MAX 0R05 R

3302 232270260105 RST SM 0603 RC21 1M PM5 R

3303 232270260101 RST SM 0603 RC21 100R PM5 R

3304 232270260101 RST SM 0603 RC21 100R PM5 R

3306 212211805678 RST SM 0603 RC0603 47K PM5 R

3307 212211805669 RST SM 0603 RC0603 10K PM5 R

3308 232270260101 RST SM 0603 RC21 100R PM5 R

3309 232270260101 RST SM 0603 RC21 100R PM5 R

3310 232270260101 RST SM 0603 RC21 100R PM5 R

3311 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3312 232270260472 RST SM 0603 RC21 4K7 PM5 R

3313 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3314 232270260472 RST SM 0603 RC21 4K7 PM5 R

3320 232270260472 RST SM 0603 RC21 4K7 PM5 R

3322 212211805669 RST SM 0603 RC0603 10K PM5 R

3323 232270260101 RST SM 0603 RC21 100R PM5 R

3324 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3325 232270296001 RST SM 0603 JUMP. MAX 0R05 R

3342 232270260472 RST SM 0603 RC21 4K7 PM5 R

3343 232270260472 RST SM 0603 RC21 4K7 PM5 R

3345 232270260101 RST SM 0603 RC21 100R PM5 R

3346 232270260101 RST SM 0603 RC21 100R PM5 R

3401 232270260101 RST SM 0603 RC21 100R PM5 R

3402 232270260101 RST SM 0603 RC21 100R PM5 R

3403 212211805637 RST SM 0603 RC0603 22R PM5 R

3404 212211805637 RST SM 0603 RC0603 22R PM5 R

3405 212211805637 RST SM 0603 RC0603 22R PM5 R

3406 232270260101 RST SM 0603 RC21 100R PM5 R

3407 232270260101 RST SM 0603 RC21 100R PM5 R

3408 212211805637 RST SM 0603 RC0603 22R PM5 R

3501 212211805639 RST SM 0603 RC0603 47R PM5 R

3502 212211805639 RST SM 0603 RC0603 47R PM5 R

3503 212211805639 RST SM 0603 RC0603 47R PM5 R

3513 232270260101 RST SM 0603 RC21 100R PM5 R

3514 232270260101 RST SM 0603 RC21 100R PM5 R

3515 232270260102 RST SM 0603 RC21 1K PM5 R

3516 212211805647 RST SM 0603 RC0603 220R PM5 R

3517 212211805647 RST SM 0603 RC0603 220R PM5 R

3518 212211805669 RST SM 0603 RC0603 10K PM5 R

3519 212211805669 RST SM 0603 RC0603 10K PM5 R

3521 212211805669 RST SM 0603 RC0603 10K PM5 R

3522 212211805669 RST SM 0603 RC0603 10K PM5 R

3523 212211805669 RST SM 0603 RC0603 10K PM5 R

3531 212211805972 RST SM 1206 JUMP. MAX 0R05 R

3533 212211805678 RST SM 0603 RC0603 47K PM5 R

3534 232270260104 RST SM 0603 RC21 100K PM5 R

3535 212211805669 RST SM 0603 RC0603 10K PM5 R

3545 212211805972 RST SM 1206 JUMP. MAX 0R05 R

5210 242254945579 IND FXD 1206 EMI 100MHZ 100R R

5415 242254900113 IND FXD 0603 EMI 100MHZ 1K R

5421 242254945579 IND FXD 1206 EMI 100MHZ 100R R

5431 242254945579 IND FXD 1206 EMI 100MHZ 100R R

5501 242254944196 IND FXD 0805 EMI 100MHZ 120R R

5502 242254944196 IND FXD 0805 EMI 100MHZ 120R R

5503 242254944196 IND FXD 0805 EMI 100MHZ 120R R

5507 242254945579 IND FXD 1206 EMI 100MHZ 100R R

5535 242254945579 IND FXD 1206 EMI 100MHZ 100R R

6201 933137390215 DIO REG SM BZX84-C5V1 (PHSE)

6204 933137390215 DIO REG SM BZX84-C5V1 (PHSE)

6205 933137390215 DIO REG SM BZX84-C5V1 (PHSE)

6206 933137390215 DIO REG SM BZX84-C5V1 (PHSE)

6302 932205042685 DIO SIG SM BAV99LG (ONSE) R

6303 933976370215 DIO SIG SM BAT54C (PHSE) R

7301 313815862461 CPU IC ASSY

7301 932220582682 IC SM NT68F633L (NOVA) L

7341 313815862481 EEPROM ASSY-LPL

7341 932218650682 IC AT24C16A-10PU-2.7 (ATME) L

7401 823827716521 NT6852AXF ANALOG XGA SCALER

7518 932217439685 TRA SIG SM BC857C (KEC0) R

7519 932217439685 TRA SIG SM BC857C (KEC0) R

7531 932216638668 FET POW SM SI5441DC-E3 (VISH)R

7532 932209265685 TRA SIG SM MUN2211JG (ONSE)

7541 932222077668 IC SM AME1117ECGTZ (ST00) R

3902 212211805678 RST SM 0603 RC0603 47K PM5 R

3903 212211805669 RST SM 0603 RC0603 10K PM5 R

3904 232270260102 RST SM 0603 RC21 1K PM5 R

3905 212211805678 RST SM 0603 RC0603 47K PM5 R

3906 212211805669 RST SM 0603 RC0603 10K PM5 R

3907 232270260102 RST SM 0603 RC21 1K PM5 R

6910 932219981682 LED VS L-3WYGW-8.03* (KIEL) B

1053 313815861661 CONTROL ASSY

Item 12NC Description

0291 313815566281 LABEL-QDI

0295 313815566281 LABEL-QDI

0615 313811708061 HEX CODE OF F/W(QDI)

1050 932221915682 TFT-LCD QD15XL13 REV01(QUDI) B

1051 313815862441 SCALER ASSY

7301 313815862471 CPU IC ASSY

7341 313815862491 EEPROM ASSY-QDI

Diversity of 150S6FG/00(QDI) compared with

150S6FG/00(LPL)
