DDC Data - 150S6
THE DISPLAY DATA CHANNEL ( DDC )2BCONTENT
INCLUDING (FOR LG & QDI PANEL ANALOG)
*****************************************************************
EDID log file
*****************************************************************
Vendor/Product Identification
ID Manufacturer Name : PHL
ID ProductCode : 0829 (HEX.)
IDSerial Number : 1E240 (HEX.)
Week of Manufacture : 45
YearofManufacture : 2004
EDID Version, Revision
Version : 1
Revision : 3
Basic DisplayParameters/Fe
atures
Video InputDefinition : Analog Video Input
0.700V/0.300V(1.00Vpp)
without Blank-to-Black Setup
Separate Sync
Composite Sync
Sync on Green
no Serration required
Maximum H Image Size : 30
Maximum V Image Size : 23
DisplayTransfer Characteristic : 2.2
(gamma)
Feature Suppor
t (DPMS):Standby
Suspend
Active Off
Display Type : RGB color display
Preferred Timing Mode : Detailed timing block 1
Color Characteristics
Red X coordinate:0.631
Red Y coordinate:0.347
Green X coordinate:0.309
Green Y coordinate:0.583
Blue X coordinate:0.15
Blue Y coordinate:0.088
White X coordinate:0.313
White Y coordinate:0.329
Established Timings
Established Timings : 720 x400 @70Hz (IBM,VGA)
640 x480 @60Hz (IBM,VGA)
640 x480 @67Hz (Apple,MacII)
640 x480 @72Hz (VESA)
640 x480 @75Hz (VESA)
800 x 600 @56Hz (VESA)
800 x 600 @60Hz (VESA)
Established Timings II : 800 x 600 @72Hz (VESA)
800 x 600 @75Hz (VESA)
832 x 624 @75Hz (Apple,Mac II)
1024 x 76
8@60Hz (VESA)
1024 x 768@70Hz (VESA)
1024 x 768@75Hz (VESA)
Manufacturer's timings :
Standard Timing Identification : Unused
Detailed Timing #1
Pixel Clock (MHz) : 65
HActive (pixels) : 1024
HBlanking (pixels) : 320
VActive (lines) : 768
VBlanking (lines) : 38
H Sync Offset (F Porch) (pixels): 24
H Sync Pulse Width(pixels) : 136
V Sync Offset (F Porch) (lines) : 3
V Sync Pulse Width (lines) : 6
HImage Size (mm) : 307
VImage Size (mm) : 230
H Border (pixels) : 0
V Border (lines) : 0
Flags : Non-interlaced
:Normal Display, No stereo
: Digital Separatesync.
:Negative Vertic
al Sync.
:Negative Horizontal Sync.
Monitor Descriptor #2
Serial Number : BZ 123456
Monitor Descriptor #3
Monitor Name : Philips 150S
Monitor Descriptor #4
Monitor Range Limits
Min. Vt rateHz : 56
Max. Vt rateHz : 76
Min. Horiz. ratekHz : 30
Max. Horiz. ratekHz : 63
Max. Supported Pixel : 80
No secondary GTF timing formula supported.
Extension Flag:0
Check sum : 54(HEX.)
**********************************************************************
EDID data (128 bytes)
**********************************************************************
0: 00 1:ff 2:ff 3:ff 4:ff 5:ff 6:ff 7:00
8: 41 9: 0c 10:29 11: 08 12: 4013: e2 14: 01 15: 00
16:2d 17: 0e 1
8: 01 19: 0320: 0e21: 1e22:17 23: 78
24: ea 25:b1 26: a5 27: a1 28: 58 29: 4f 30:95 31:26
32: 16 33: 50 34: 5435:bf 36: ee 37: 00 38: 01 39: 01
40: 01 41: 01 42: 01 43: 01 44: 01 45: 01 46: 01 47: 01
48: 01 49: 01 50: 01 51: 01 52: 01 53: 01 54: 64 55: 19
56: 00 57: 405
8: 4159: 00 60:2661:3062: 18 63: 88
64: 3665: 00 66:33 67: e668: 10 69: 00 70: 00 71: 18
72: 00 73: 00 74: 00 75:ff 76: 00 77: 20 78: 42 79: 5a
80:20 81:20 82: 31 83: 32 84: 33 85:34 86:35 87: 36
88: 0a 89: 20 90: 00 91: 00 92: 00 93: fc 94: 00 95: 50
96: 68 97: 69 98: 6c 99: 69 100
:70 101:73102: 20103: 31
104: 35 105:30106: 53 107: 0a 108: 00 109: 00 110: 00 111:fd
112: 00 113: 38 114: 4c 115: 1e 116:3f117: 08 118: 00 119: 0a
120:20121:20122: 20123: 20124: 20125:20126: 00 127: 54
