Philips 170B2M - Optical Characteristics

VIDEO
• Video dot rate 135MHz
• Input impedance
- Video 75 Ohm
- Sync 2K Ohm
• Input signal levels 0.7 Vpp
• Sync input signal
Separate sync
Composite sync
Sync on green
• Sync polarities Positive and negative
• Video interface
Triple input (two connectors): D-Sub (analog) and DVI-I (accepts
both digital and analog) are available and user selectable
AUDIO
• Input signal level 0.7 Vpp
• Headphone out signal level 32 Ohm 20+20mW
• Input signal connector 3.5mm mini jack
• Loudspeaker 2+2W RMS stereo front firing (PMPO: 48W)
MICROPHONE
• Sensitivity -55dB re 1V/ubar at 1KHz
• Output impedance 2.2K Ohm max.
• Directivity -5dB at 180°
• Frequency range 300Hz-3KHz
Optical characteristics
• Contrast ratio: 400 (typ.)
• Brightness:
250 cd/m
2
(typ.)
• Peak contrast angle 6 o'clock
• White Chromatcity:
x: 0.281 y: 0.311 (at 9300°K)
x: 0.312 y: 0.338 (at 6500°K)
170B2M Product Information
