General Product Specification
8639 000 16452
2005-04-25
590
7
26
Peter.V
17 inch TFT-LCD Monitor
TYPE : 170C6FS/00
BRAND : PHILIPS
2005-04-25
3.0Electrical characteristics
3.1Interfacesignals
1). D-shell Analog
Input signal: Video, H-sync,V-sync,
Video: 0.7 Vp-p, inputimpedance, 75 ohm
Sync. :Separatesync TTL level, inputimpedance 2k2ohm term
inate
H-sync Positive/Negative
V-sync Positive/Negative
Compositesync TTL level, inputimpedance 2k2ohm terminate
(Positive/Negative)
Sync on green video0.3V p-p Negative. (Video0.7 Vp-p Positive)
3.2Interface
3.2.1D-S
ub Cable
Length. :1.8 M +/- 50 mm
Connector type. :D-Sub male with DDC-2B pin assignments.
Blue connector thumb-operated jackscrews
Pin Assignment:
PIN No. SI GNAL
1Red videoinput
2 Green videoinput/sync on green
3 Blue videoinput
4 GND
5 GND- Cable detect
6Red video GND
7 Green video GND
8 Blue video GND
9 DDC +3.3V or +5V
10 Logic GND
11 GND
12 Serial dataline(SDA)
13 H-sync / H+V
14 V-sync
15 Data clockline(SCL)
