190CW7 LCD
Electrical Instructions
1 Electrical characteristics
1.1 Interface signals
1). D-Sub Analog
Input signal : Video, Hsync., Vsync
Video : 0.7 Vp-p, input impedance, 75 ohm @DC
Sync. : Separate sync TTL level , input impedance 2.2k ohm terminate
Hsync Positive/Negative
Vsync Positive/Negative
Composite sync TTL level, input impedance 2.2k ohm terminate(Positive/Negative)
Sync on green video 0.3 Vp-p Negative (Video 0.7 Vp-p Positive)
2). Intel DVI Digital
Input signal : Four channel TMDS signal
1.2 Interface
1.2.1 D-Sub Cable
Length : 1.8 M +/- 50 mm (fixed) , fix in monitor and with transplant pin protect cover.
Connector type : D-Sub male with DDC2B pin assignments.
Blue connector thumb-operated jack screws
1.3 Timing requirement
1.3.1 Mode storing capacity
Factory preset modes : 20
Preset modes : 40
User define modes : 24
Note: 1. Screen displays perfect picture at 17 factory-preset modes.
1.3.2Factory preset modes (20 modes)
Item H.Freq. Mode Resolution V.Freq. Item H.Freq. Mode Resolution V.Freq
1 31.469 DOS 720x400 70.087 11 60.023 VESA 1024x768 75.029
2 31.469 VESA 640x480 59.940 12 67.500 VESA 1152x864 75.000
3 37.861 VESA 640x480 72.809 13 47.712 VESA 1360x768 60.015
4 37.500 VESA 640x480 75.000 14 55.935 VESA 1440x900 59.887
5 35.156 VESA 800x600 56.250 15 70.635 VESA 1440x900 74.984
6 37.879 VESA 800x600 60.317 16 35.000 MACINTOSH 640x480 67.000
7 48.077 VESA 800x600 72.188 17 49.700 MACINTOSH 832x624 75.000
8 46.875 VESA 800x600 75.000 18 60.000 VESA 1280x960 60.000
9 48.363 VESA 1024x768 60.004 19 79.976 VESA 1280x1024 75.025
10 56.476 VESA 1024x768 70.069 20 64.744 VESA 1400x1050 59.948
