Philips 190CW7CS/00 - Page 52

52
190CW7 LCD
22
9
GENERAL PRODUCT SPECIFICATION(Continued)
3.3 Timing requirement
3.3.1 Mode storing capacity
Factory preset modes : 20
Preset modes : 40
User define modes : 24
Note: 1. Screen displays perfect picture at 17 factory-preset modes.
2. Screen displays visible picture with OSD warning when input modes are the
33 preset modes
3.3.2 Factory preset modes (20 modes)
Item H.Freq.
(
KHz
)
Mode Resolution V.Freq.
(
Hz
)
Item H.Freq.
(
KHz
)
Mode Resolution V.Freq
.
(
Hz
)
1 31.469 DOS 720x400 70.087 11 60.023 VESA 1024x768 75.029
2 31.469 VESA 640x480 59.940 12 67.500 VESA 1152x864 75.000
3 37.861 VESA 640x480 72.809 13 47.712 VESA 1360x768 60.015
4 37.500 VESA 640x480 75.000 14 55.935 VESA 1440x900 59.887
5 35.156 VESA 800x600 56.250 15 70.635 VESA 1440x900 74.984
6 37.879 VESA 800x600 60.317 16 35.000 MACINTOSH 640x480 67.000
7 48.077 VESA 800x600 72.188 17 49.700 MACINTOSH 832x624 75.000
8 46.875 VESA 800x600 75.000 18 60.000 VESA 1280x960 60.000
9 48.363 VESA 1024x768 60.004 19 79.976 VESA 1280x1024 75.025
10 56.476 VESA 1024x768 70.069 20 64.744 VESA 1400x1050 59.948
BRAND : PHILIPS
19 inch TFT WXGA LCD Monitor
TYPE : 190CW7CS/00
8639 000 17256
2006-06-22
2006-06-22
590
