GENERAL PRODUCT SPECIFICATION(Continued)
sRGBCIE coordinates X = 0.313 ± 0.015
Y = 0.329 ± 0.015
5Mechanical characteristics
5.1 Cosmetic- Philips
TPV ID
5.2 Mechanical datafiles- ProE filesrequired
5.3 Location of Philips logo - Per Philips make-upsheet
Gap between paneland front bezel<1.2 mm
Location ofControl icons- Per Philips Graphic
Sheet
Front side: Per Philips graphicsheet
Rear : Per Philips graphicsheet
5.4 Colorforresin/paint - Per Philips make-upsheet
5.5 Resins
· RoHS required
· WEEE required.
· Resin type/selection refer
to Project Book Section 7.2 Plasticmaterial.
5.6 Ifpaint is used
· RoHS required
· WEEE require
5.7 Plasticmoldtooling
· Tooling to bedesigned to minimize cosmetic defects induced by moldingprocess
(sink, blush, weld
lines, gate marks, ejector marks, etc.).
· Painting to cover upcosmetic defect s due to molding i sstrongly discouraged.
5.8 Plastics flammability
· All Plastics to beFlameRetardant UL 94-V0 orBetter (ifmonitorweighs l
ess than 18kg; UL94-V0 is
OK).
· All majorplastic parts (bezel, back cover ) need to be molded fromsame resin.
5.9 Texture/Glossing ofhousing
· Thetexture areaand texturenoshould follow Philips make
-upsheet TP V Spec.
· Theexteriorsurfaces shall have a uniform texture.
· Philips must approvethe moldtexturing.
· Detail document for texture refer to UAN-D249.
· <=20gloss units
