Philips 190CW8FB/00 - Repair Flow Chart

Philips 190CW8FB/00
95 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
80
HUDSON 8
AC IN
Power Board
Control Board
Scaler Board
LCD Panel
No power
(power indicator off)
Check 12V/5V
NG
Bad power board
Check Control Board
Check Control Wires
Check Scaler Board
OK
NG
OK
Bad Scaler Board
Check LCD Panel
OK
Repair Flow Chart
