220B2 22” Wide 16:10 LCD Monitor
2010/02/10 PHILIPS 11 of 29
64 220BL2 LCD
General Product Specification
3.3 Timing requirement
Factory Preset mode definition: (1)Perfect FOS while presenting those timings. (2)Will specify those
timing in User's Manual
Preset mode definition:(1)Need to support those timings.(2)Perfect FOS after auto adjustment.
User mode:(1)Can save those timing that not in Preset mode and can be showed (not over scaler or
Panel spec.)(2)It needs to reserve the 10 timings space in memory size.
3.3.1 Mode storing capacity
Factory preset modes : D-sub :18 , DVI : 17
Preset modes : 45 User modes : 10
3.3.2 Factory preset modes ( D-sub18 modes)
1. Factory modes and preset modes are defined in the enclosed timing table file
ˣ˻˼˿˼ʳ˅˃˪˲˅˅˪ʳ
˧˼˼˺ʳ˧˴˵˿˸
2. Video timing mode (internal firmware support) ,
60Hz: 480p/720p/1080i/1080p
50Hz: 576p/720p/1080i/1080p
For these video timings , can only approve shown on screen, but not make sure has right picture quality.
3.3.3 Software control functions via OSD / control adjustable functions:
Please refer to following M1 OSD definitions, if any deviation, then refer to PVT Exit sample.
ITEM
1 OSD DEFINITIONS
˛˷ʳˋʳˢ˦˗ʳ
˗˸˹˼˼˼ʳˀʳ˄ˇˁ˷˶
Reset -
No: Exit
Yes: Auto adjustment for displaying
timing mode and recall factory preset
2 OSD LANGUAGES
˛ˋʳˢ˦˗ʳ˴˿˴˼ʳˀʳ
˅˃˃ˊ˃ˇ˅ˈʳˀʳ˙˼˴˿ˁ˿
˛ˌʳ˸ʳ˼˸ʳ
˴˿˴˼ʳ˲ʳ˅˃˃ˋ˃ˇ˄
8 LANGUAGES
3 OSD TREE
ˠ˅ʳˢ˦˗ʳ˕ʳ
˷˸˹˼˼˼ʳ˲ʳ˅˃˄˃˃˄˅
ˈ
4 POWER ON LOGO
˅˅˪˲˄ˉˋ˃˄˃ˈ˃ˁ˼
Power On Logo: Power On Æ Show up
Philips logo 3 seconds
This picture is reference only. The
official drawing will send out by PM.
5 Audio Selection Stand-alone – On:
Isolate video and audio control
Stand-alone – Off:
Integrate video and audio control
input
Mute – On: Turn off audio
Mute – Off: Turn on audio
