220B2 22” Wide 16:10 LCD Monitor
2010/02/10 PHILIPS 18 of 29
220BL2 LCD 71
General Product Specification
4 Visual characteristics
4.1 Test conditions
Unless otherwise specified, this specification is defined
under the following conditions.
(1) Input signal : As defined in 3.3, 1680 x 1050 non-interlaced mode (1680 x 1050@75Hz), signal
sources must have 75 ohm output impedance.
(2) Luminance setting : controls to be set to 300 nits with full screen 100 % duty cycle white signal
(3) Warm up: more than 30 minutes after power on with signal supplied.
(4) Ambient light: 400 -- 600 lux.
(5) Ambient temperature: 20 ± 5 qC
4.2 Brightness
Follow Panel specification.
4.3 Image size
Actual display size 473.76 mm x 296.10 mm
4.4 Brightness uniformity
Set contrast at 100% and turn the brightness to get average above 250 nits at centre of the
screen.
Apply the Fig 1, it should comply with the following formula:
( B_max - B_min )
X 100% > 75%
B_max
Where B_max = Maximum brightness
B_min = Minimum brightness
4.5 Check Cross talk (S)
Apply Pattern 2. Set contrast and brightness at 100 %.
Measure YA. Then output Pattern 3 and measure YB.
the cross talk value :
ABS ( YA - YB )
X 100% < 1.5 %
YA
