Philips 220VW9FB/97 - Mechanical Instructions

HUDSON 9
36
10. Mechanical Instructions
1. Back View as Fig1
Place the monitor face down on a smooth surface as Fig 1. Be careful to avoid scratch and injury during the
uninstallation.
Fig1
2. Remove the hinge as Fig2.
Remove the three screws remarked in red to remove the hinge as Fig2.
Fig2
