Philips 22PFT5403/56 - IR;LED Panel; IR LED Schematic

9.4 J 715G8576 IR/LED Panel
9-4-1 IR LED
LED_R
LED_R
IR
C1
2.2uF 10V
VCC
LED1
GPSS008RC4
12
R5
22K 1/16W 5% Q1
BC847BW
R2
2K7 1/16W 5%
R7
22K 1/16W 5%
C2
100N 16V
VCC
ZD2
NC/MLVG0402
1 2
ZD1
NC/MLVG0402
1 2
VCC
R1
15K 1/16W 5%
U1
TSOP75436TR
GND
1
VCC
2
Vout
3
GND
4
CN1
CONN
1
2
3
4
5
67
033G8032 5F S HR
