FOREWORD
This specification describes a 23" FHD multi-scan color TFT LCD monitor with maximum
resolution up to 1920 x 1080 /60Hz non-interlaced. This model uses 250nits panel.
All optical characteristics are determined according to panel specification after warming
up longer than 30 minutes.
PRODUCT PROFILE
EDID header
Data for EDID & .inf file
1 User visible strings on .inf file
Philips 237E (23inch Wide LCD MONITOR
237E4)
2 Manufacturer ID ( EDID data) PHL
3 Product ID, "xxxx" 4 codes MSB(byte 12): C0
LSB (byte 11): AD
4 maximum resolution 1920x1080
5 Horizontal Frequency Range 30~83 KHz
6 Vertical Frequency Range 56~76Hz
7 Monitor Name (13 characters max.) Philips 237E
LCD
Suppliers to offer panel specifications.
Panel incoming specification: Follow Philips’ specification.
LnT
Type NR. : LnT BM230WF3-SJC2 e-IPS panel
Resolution : 1920 x 1080 (WSXGA+)
Outside dimensions : 534(H) x 313.3(V) Typ. x 10.6(D) Typ.
Pitch (mm) : 0.265mm x 0.265mm
Color pixel arrangement : RGB vertical stripe
Display surface : Hard coating (3H)
Color depth : 16.7M (6 bit Hi-FRC)
Backlight : LED
Active area (W x H) : 509.76(H) x 286.74(V) mm
View angle (CR=10) : =178 for Right/Left (Typ)
: =178 for Up/Down (Typ)
Contrast ratio : 1000:1 (Typ), 600:1(Min.)
White luminance : 250cd/m2(Typ.), 200cd/m2(Min.)
Color gamut : 70% (Typ.)
Gate IC : N/A
Source IC : N/A
Response time : Tr + Tf <=14 ms (Typ)
Vertical frequency range : 48~76Hz
LnT
Type NR. : LnT BM230WF5-TJC3
Resolution : 1920 x 1080 (WSXGA+)
Outside dimensions : 536.5(H) x 312(V) Typ. x 8.4(D) Typ.
Pitch (mm) : 0.265mm x 0.265mm
Color pixel arrangement : RGB vertical stripe
Display surface : Hard coating (3H), Anti-glare treatment of the front polarizer
Color depth : 16.7M colors
Backlight : LED
