PARTS LIST [32PFL4909/F7 (Serial No.: ME1)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
LCD PANEL ASSEMBLY#
Ref. No. Description Part No.
A3 REAR CABINET A4DFAUT 2EMM00312
A7 FUNCTION KNOB A4GF1UT 2EMM00237
A8 KNOB FRAME A4DFAUT 2EMM00325
A11 STAND NECK A31M2UT 1EM228000A
A13 JACK HOLDER A3RF0UT 1EM334677
A15# RATING LABEL A4DF2UT ----------
A16 LOGO LABEL A4DFAUT ----------
A17 ENERGY GUIDE LABEL A4DF2UT ----------
AC601# AC CORD W/O A GND WIRE UL/CSA/1775/NO/
BLACK
WAC172LTE010
B10 STAND HOLDER A4GF1UT 2EMM00233
B12 SENSOR SHIELD A4GF1UT 2EMS00133
B17 WALL_MOUNT_BRACKET A11N0UH 1EM434637
B18 WALL_MOUNT_COVER A2170UT 1EM332137
B23 WIRE LABEL A3AF0UT ----------
CL3101 FFC WIRE ASSEMBLY 9PIN 9PIN/WHITE/
292MM
WX1A4GF0S112
CL3102 WIRE ASSEMBLY 2PIN 2PIN/339MM WX1A4GF0C312
CL3701 FFC WIRE ASSEMBLY 23PIN 23PIN/WHITE/
213MM
WX1A4DF2S121
CL3801 WIRE ASSEMBLY 4PIN 4PIN/
56MM&61MM&362MM
WX1A4GF0C321
L9 SCREW BIND BLACK_NI +P-TITE M3X12.0
3X12 BIND HEAD+ BLK
GBHP3120
L23 SCREW BIND 3CHROM +S-TITE M3X6.0 M3X6
BIND HEAD+
GBJS3060
L27 SCREW BIND BLACK_NI +S-TITE M3X8.0
M3X8 BIND HEAD+
GBHS3080
SBA1 STAND BASE ASSEMBLY A31M2UT 1ESA34000
SP3801 SPEAKER MAGNETIC 8OHM/8W S0310F14 DS08110XQ002
SP3802 SPEAKER MAGNETIC 8OHM/8W S0310F14 DS08110XQ002
SSK1 STAND SCREW KIT A31M2UT(SCREW BIND
BLACK_NI +P-TITE M4X25.0 )
1ESA34003
PAC KI NG
S1 CARTON A4DF2UT 2EMC00338
S3 STYROFOAM TOP A4GF1UT 2EMC00274
S4 STYROFOAM BOTTOM A4GF1UT 2EMC00275
S6 SET BAG A31F0UT 2EMC00088
S7 SERIAL NO. LABEL A4GF1UT ----------
ACCESSORIES
X1 POLYETHYLENE BAG HDPE 180X340XT0.03 1EM435579
X2# OWNERS MANUAL A4DFAUT 2EMN00159
X3 REMOTE CONTROL UNIT YKF340-003 URMT41JHG003
X4 BATTERY DRY R03(SIZE AAA ) XB00M0RKT001
X6 QUICK START GUIDE A4DF2UT 2EMN00165
Ref. No. Description Part No.
LCD1# LCD PANEL ASSEMBLY U44F4PA
Consists of the following
A5 DECORATION PLATE A4DFAUT 2EMH00294
A9 LED LENS A4DFAUT 2EMM00301A
A20 LEADING EDGE COVER A4DFAUT 2EMM00288
CL3006 FFC WIRE ASSEMBLY 30PIN(W/SHIELD) 30P/
FFC/SHIELD/629MM
WX1A4DF2P401
LCD MODULE ----------
