Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DIGITAL MAIN CBA UNIT
MSW ASSEMBLY
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A4DF2MMA-001
CN3701 WIRELESS LAN MODULE WM5504 UWLMDLACM002
IC3101 IC MAIN PH1-SLD8PLUS MN2WS0270HA QSCA0R0MS065
IC3102 IC NAND FLASH 1GB H27U1G8F2BTR-BC NSCA0R0HY009
IC3103 16KBIT EEPROM M24C16-WMN6TP NSZBA0TSS259
IC3601 IC RESET IC-PST8429UR QSCA0T0MM075
IC3602 IC DC-DC CONVERTER MP1472GJC452Z NSCA0T09M021
IC3603 IC DC-DC CONVERTER MP1472GJC452Z NSCA0T09M021
IC3604 IC DCDC CONVERTER RT8293ALZSP NSCA0T00B017
IC3607 IC DC-DC CONVERTER MP1472GJC452Z NSCA0T09M021
IC3701 IC USB HIGH-SIDE SW AP2151WG-7/SOT25/
5PI
NSCA0TDES015
IC3803 IC D-CLASS AUDIO POWER AMPLIFI
TPA3110D2PWPR
NSCA0T0TY073
TU3001 TUNER UNIT U9004UT U9004UT
When you replace one of the below ICs on this CBA, always replace the
IC in accordance with the 4 combinations below. Do not mix ICs of
different combination.
IC3401 IC 1GB DDR3 SDRAM K4B1G1646G-BCK0 NSCA0R0SM055
IC3402 IC 2GB DDR3 SDRAM K4B2G1646Q-BCMA NSCA0R0SM057
or
IC3401 IC 1GB DDR3 SDRAM H5TQ1G63EFR-PBC NSCA0R0HY039
IC3402 IC 2GB DDR3 SDRAM H5TQ2G63FFR-PBC NSCA0R0HY041
or
IC3401 IC 1GB DDR3 SDRAM NT5CB64M16FP-DH NSCA0R0J2017
IC3402 IC 2GB DDR3 SDRAM NT5CB128M16FP-DI NSCA0R0J2016
or
IC3401 IC 1GB DDR3 SDRAM H5TQ1G63EFR-PBC NSCA0R0HY039
IC3402 IC 2GB DDR3 SDRAM H5TQ2G63DFR-PBC/
FBGA
NSCA0R0HY034
Ref. No. Description Part No.
MSW ASSEMBLY
Consists fo the following
A4DFAMSW-001
FUNCTION CBA UNIT A4DFAMSW-001-FN
IR SENSOR CBA UNIT A4DFAMSW-001-IR
Ref. No. Description Part No.
POWER SUPPLY CBA
Consists fo the following
A4DFAMPW-001
CAPACITORS
C602# CAP CERAMIC SAFETY 1000pF/250V E M KX CJMR102M42E1
C603# CAP CERAMIC SAFETY 1000pF/250V E M KX CJMR102M42E1
C604# CAP METALLIZED FILM 0.22µF/275V/K CTA224PKR001
C605 CAP ELE 330µF/200V/M/87 CEB3310S6016
C606 CERAMIC CAP. 820pF/2kV CA3D821PAN04
C607 CHIP CERAMIC CAP. B K 1800pF/50V CHD1JK30B182
C608 CHIP CERAMIC CAP.(1608) B K 0.015µF/50V CHD1JK30B153
C609 CHIP CERAMIC CAP. B K 0.068µF/50V CHD1JK30B683
C610 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C614# CAP METALLIZED FILM 0.22µF/275V/K CTA224PKR001
C616# CAP CERAMIC SAFETY 1000pF/250V E M KX CJMR102M42E1
C617 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C618 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C623 CHIP CERAMIC CAP.(1608) B K 4.7µF/6.3V CHD0KK30B475
C651 CAP ELE 470µF/25V/M/85 CED4710V8006
C652 CAP ELE 470µF/25V/M/85 CED4710V8006
C653 CAP ELE 470µF/25V/M/85 CED4710V8006
C654 CAP ELE 470µF/16V/M/85 CEC4710V8006
C655 CAP ELE 470µF/16V/M/85 CEC4710V8006
C656 CAP ELE 1µF/50V/M/85 CEF1R00V8006
C660 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C663 CAP ELE 100µF/10V/M/85 CEB1010V8006
C665 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C666 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1001 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1002 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1003 CAP ELE 470µF/25V/M/85 CED4710V8006
C1005 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1006 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1007 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C1008 CHIP CERAMIC CAP. B K 560pF/50V CHD1JK30B561
C1009 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1010 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1012 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1013 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1014 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1015 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1017 CAP ELE 47µF/100V/M/85 CEH4700V8006
C1018 CAP ELE 47µF/100V/M/85 CEH4700V8006
C1021 CAP ELE 47µF/100V/M/85 CEH4700V8006
CONNECTORS
CN501 FPC/FFC CONNECTOR IMSA-9615S-23C-PP-
A
JC96J23ER009
CN601# CONNECTOR S2P3-VH (LF)(SN) JCVHC02JG002
CN1001 PH CONNECTOR TOP 2P B2B-PH-K-S
(LF)(SN)
J3PHC02JG029
DIODES
D601# DIODE 1N5397BD NDL1001N5397
D602# DIODE 1N5397BD NDL1001N5397
D603# DIODE 1N5397BD NDL1001N5397
D604# DIODE 1N5397BD NDL1001N5397
D605 ZENER DIODE MM5Z4V3B ND1BMM5Z4V3B
D607# ZENER DIODE SMD TFZVTR27B QD1B00TFZV27
D608# DIODE ZENER 1ZB36BB NDWZ0001ZB36
D609 DIODE SCHOTTKY SMD CES520.L3F(D QD1Z00CES520
D610 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
