g BATHROOM SPEAKER 8
Audio output to a bathroom speaker
(1W) via a stereo jack.
(Before you connect the bathroom
speaker, make sure to turn off the TV
mains power.)
h CVI (Y Pb Pr and AUDIO L/R)
Analog audio and video input from analog
or digital devices such as DVD players or
game consoles.
AWG < 16
BATHROOM
SPEAKER 8
BATHROOM
SPEAKER 8
NC
Speaker Terminal “+”
Speaker Terminal “-”
CVI
e AV-IN
Audio or composite video input from
analog devices connected to VIDEO or
VCRs.
AV-IN
f AV-OUT
Audio L/R: Analog audio output to home
theaters or other audio systems.
AV-OUT
VIDEO: Analog video output to external
devices such as another TV set.
AV-OUT
