Philips 32PFL3008D/78 - Wiring diagram 3000 series 39

EN 34TPS10.1L LA 9.
Block Diagrams
2013-Apr-26
back to
div.table
9.2 Wiring diagram 3000 series 39"
19500_401_130412.eps
130412
WIRING DIAGRAM 39" (3000 series)
Board Level Repair
Component Level Repair Only for authorized workshops
See note in Chapter 7 about cable position numbers
KEYBOARD CONTROL
(1057)
E
LOUDSPEAKERLOUDSPEAKER
(1185)(1185)
J
LOUDSPEAKER
(1185)
LOUDSPEAKERLOUDSPEAKER
(1185)(1185)
LOUDSPEAKER
(1185)
SSB (1053)
B
LN
CN9902
MAIN POWER SUPPLY (1054)
A
13P
12P
IR/LED BOARD (1056)
6P
3P
CN016
HDMI 2
ARC
USB
TV ANTENNA
YPr Pb
CVBS R
L
HDMI1
AUDIO
CN9101
CN8101
TO PANEL
TO PANEL
13P
4P
CN601
CN701
42P
CN403
12P
CN201
SERV.U
CN401
