Philips 32PHD5813/55 - Page 55



9.5 J 715G8009 IR/LED Panel （For 5833 Series）
9-5-1 IR & LED & Light Sensor
Stand LED Light Sensor
IR Receiver
S t a n d b y L E D
RC-IR
3V3SB
LS_SCL
LS_SDA
DVD3V3
LED201
GPSS008RC4
12
Red
DVD3V3
U221
NC/JSA-1130
ADDR
1
VDD
2
GND
3
SCL
4
SDA
5
INT
6
R224
NC /0R 05 1/16W
Light Sensor
Digital Light Sensor
R222
NC/10K 1/16W 5%
R221
NC/10K 1/16W 5%
C222 NC/1uF 10V
LS_SDA
LS_SCL
JSA-1130
R223
NC /0R 05 1/16W
JSA-1130
R224 R223 I2C a ddr
0R
0RNC
NC 0x44
0x45
C221 NC/100N 16V
LS_SCL
LS_SDA
DVD3V3
LED_R
R202
22K 1/16W 5%
Q201
BC847BW
LED_R
R201
2K7 1/16W 5%
CN201
1
2
3
4
5
6
7
8
9
10
11
12
13
1415
3V3SB
C201
1uF 10V
3V3SB
R204
100R 1/16W 5%
R203
NC/2K7 1/16W 5%
RC-IR
C202
1uF 10V
Close to U201
Close to U201
IR Receiver
3V3SB
ZD201
MLVG0402
12
U201
TSOP75436TR
GND
1
VCC
2
Vout
3
GND
4
