Philips 32PHD5813/55 - 715 G9740 Keyboard Control Panel



9.6 E 715G9740 Keyboard control panel
9-6-1 Key
KEY1
Menu
Right
Left
Down
Up
6-5 short
R04
2K2 1/10W 1%
2-5 short
F1
R01
1K2 1/10W 1%
3-5 short
1-5 short
4-5 short
F2
F5
F3
F1
F4
F2
SW01
TACT SW 6P
3 4
2
1 6
5
7
8
F3
F4
F5
R05
15K 1/10W 1%
R03
6K8 1/10W 1%
Direction switch
----><----|
C06
0.1uF 50V
Joystick circuit diagram
pin1
0V
0.5V
0.81V
1.65V
2.27V
pin2
No function
pin3
3.3V
C04
NC/100N 50V
pin4
C05
NC/100N 50V
pin5 pin6
----><----|
C01
NC/100N 50V
C02
NC/100N 50V
C03
NC/100N 50V
----><----| ----><----| ----><----|
Center
Up
Down
CN01
CONN
1
2
34
R02
0R05 1/10W
0R
2K2
ResistanceKey function
Center
CH-
CH+ 1K2
VOL+
VOL-
Left
6K8
15K
Right
Range
0.39 to 0.60 V
0 to 0.22V
1.93 to 2.58 V
1.41 to 1.87 V
0.67 to 0.95 V
3.135 to 3.465 V
Voltage
JOYSTICK
