Philips 39” LCD TV - Wiring Diagram

PL13.11AWI11-1
WIRING DIAGRAM
1
23
CN501
1
23
CN3601
1
51
CN3906
9 1
CN4052
1 9
CN3105
111
CN1001
BW
CN601
DIGITAL MAIN CBA UNIT POWER SUPPLY CBA
FUNCTION CBA UNIT
LCD PANEL ASSEMBLY
AC CORD
ETHERNET JACK
CL3701
CL3011
CL3101
WIRELESS LAN MODULE
14
CN3801
SP3801 SPEAKER L-CH
SP3802 SPEAKER R-CH
CL3801
TUNER UNIT
COMPONENT -Y/VIDEO-IN COMPONENT -Pb-IN COMPONENT -Pr-IN AUDIO(L)-IN AUDIO(R)-IN
REAR
DIGITAL AUDIO-OUT (COAXIAL)
HDMI- CONNECTOR-1 HDMI- CONNECTOR-2 HDMI- CONNECTOR-3
PC-RGB-IN USB JACK
SIDE
HEADPHONE JACK
[TYPE A]
