Philips 39” LCD TV - PARTS LIST [TYPE A]; Mechanical Parts List

2013/02/18 13-1 A3RTBCA.fm
TYPE A
PARTS LIST [39PFL2608/F7 (Serial No.: DS1)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
LCD PANEL ASSEMBLY
Ref. No. Description Part No.
A3 REAR COVER A3RP0UH 1EM030705
A13 JACK HOLDER A37U0UH 1EM334736
A15# RATING LABEL A3RTBUH ----------
A16 LOGO LABEL A3RM0UT ----------
A17 ENERGY GUIDE LABEL A3RTBUH ----------
AC601# AC CORD W/O A GND WIRE UL/CSA/1700/NO/
BLACK
WAC172LTE005
B10 STAND HOLDER A31T0UH 1EM127914
B17 WALL MOUNT BRACKET A11N0UH 1EM434637
B18 WALL MOUNT COVER A2170UT 1EM332137
B23 WIRE LABEL A3AF0UT ----------
CL3101 FFC WIRE ASSEMBLY 9PIN 9PIN/WHITE/
130MM
WX1A31T0S102
CL3701 FFC WIRE ASSEMBLY 23PIN 23PIN/WHITE/
75MM
WX1A3RP0S101
CL3801 WIRE ASSEMBLY 4PIN 4PIN/320MM&90MM WX1A31T0C301
L9 SCREW P-TIGHT 3X12 BIND HEAD+ BLK GBHP3120
L23 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L27 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L67 SCREW S-TIGHT M3X10 BIND HEAD+ GBJS3100
SBA1 STAND BASE ASSEMBLY A31T0UH 1EM030366
SNA1 STAND NECK ASSEMBLY A31T0UH 1EM030365
SP3801 SPEAKER MAGNETIC 8Ω/8W S0310F15 DS08110XQ003
SP3802 SPEAKER MAGNETIC 8Ω/8W S0310F15 DS08110XQ003
SSK1 STAND SCREW KIT A31T0UH(DOUBLE SEMS
SCREW M4X20 + BLK)
1ESA34647
SSK2 STAND SCREW KIT A31T0UH(DOUBLE SEMS
SCREW M4X10 + BLK)
1ESA34648
PAC KING
S1 CARTON A3RTBUH 2EMC00041
S3 STYROFOAM TOP A31T0UH 1EM030609
S4 STYROFOAM BOTTOM A31T0UH 1EM030610A
S6 SET BAG A31PBUH 2EMC00084
S7 SERIAL NO. LABEL A01PBUH ----------
ACCESSORIES
X1 POLYETHYLENE BAG HDPE 180X340XT0.03 1EM435579
X2# OWNERS MANUAL A3RT0UH 2EMN00086
X3 REMOTE CONTROL UNIT YKF340-001 URMT39JHG003
X4 BATTERY R03-B500/01S XB0M451CZB01
X6 QUICK START GUIDE A3RT0UH 1EMN30387
X7 REGISTRATION CARD(PHILIPS) A11P4UH 1EMN27321
Ref. No. Description Part No.
LCD1# LCD PANEL ASSEMBLY U30T1P1
Consists of the following
A1 FRONT CABINET A31T2UH 1EM127996
A4 X -PCB COVER A31T0UH 1EM228323
A6 CONTROL PLATE A31F0UT 1EM334317
A9 SENSOR LENS A31F0UT 1EM334217
B12 SHIELD PLATE A31F0UT 1EM334218
CL3011 FFC WIRE ASSEMBLY 51PIN(W/SHIELD) 51P/
FFC/SHIELD/307MM
WX1A3RT0P402
L9 SCREW P-TIGHT 3X12 BIND HEAD+ BLK GBHP3120
LCD MODULE ----------
