Philips 39” LCD TV - Page 91

2013/03/14 13-12 A31TCEL.fm
Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Different parts from the original model
39PFL2608/F7 (Serial No. : DS1)
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A31TCMMA-001
CN3701 Not used
IC3001 IC DC-DC CONVERTER MP1472GJC452Z NSCA0T09M021
IC3002 IC 512MB DDR2 SDRAM K4T51163QJ-BCE7 NSCA0R0SM048
IC3003 IC DC-DC CONVERTER MP1472GJC452Z NSCA0T09M021
IC3004 IC REGULATOR BD00IA5WEFJ-E2 QSCA0T0RM233
IC3005 IC DTV-C7V R8A05011BG-U0/256FHP QSAA0R0HT057
IC3006 32MBIT C-MOS SERIAL FLASH
S25FL032P0XMFI010 /S
QSCA0R0FJ008
IC3007 IC LDO REGULATOR BD00IC0WEFJ/HTSOP-
J8
QSCA0T0RM397
IC3008 IC DC-DC CONVERTER MP1472GJC452Z NSCA0T09M021
IC3009 IC RESET IC-PST8429UR QSCA0T0MM075
IC3011 IC EEPROM BU9883FV-WE2 QSCA0T0RM105
IC3013 IC SINGLE BUS BUFFER 74LVC1G126GW NSCA0TNXP004
IC3014 IC SINGLE BUS BUFFER 74LVC1G126GW NSCA0TNXP004
IC3018 IC HDMI SW TMDS351PAGR /PAG-64 NSCA0T0TY068
IC3019 IC USB HIGH-SIDE SW AP2151WG-7/SOT25/
5PI
NSCA0TDES015
IC3101 Not used
IC3102 Not used
IC3103 Not used
IC3601 IC REGULATOR AP2121AK-3.3TRE1 NSCA0TBCD026
IC3602 Not used
IC3603 Not used
IC3604 Not used
IC3607 Not used
IC3701 Not used
IC3801 IC D-CLASS AUDIO POWER AMPLIFI
TPA3110D2PWPR
NSCA0T0TY073
IC3803 Not used
IC3851 IC HEADPHONE AMP BH3547F SOP 8PIN QSZBA0TRM119
TU3901 TUNER UNIT U9001UH U9001UH
TU3001 Not used
IC3401 Not used
IC3402 Not used
FUNCTION CBA UNIT A31TCMSW-001
POWER SUPPLY CBA A31TBMPW-001
C662 CAP ELE 22µF/50V/M/85 CEF2200V8006
IC651 IC REGULATOR AP1117E33G-13 /3PIN NSCA0TDES017
R676 WIRE CP STP-S-0.50 XZ40F0REN001
R678 METAL OXIDE RES. 2W J 0.3 Ω RN02R30ZU001
R679 METAL OXIDE RES. 2W J 0.3 Ω RN02R30ZU001
R683 RES CHIP 3216 1/4W 0 Ω RRX4000HH036
R684 RES CHIP 3216 1/4W 0 Ω RRX4000HH036
Ref. No. Description Part No.
