Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Different parts from the original model
39PFL2608/F7 (Serial No.: DS1)
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A31T2MMA-004
CN3701 Not used
IC3001 IC MSD8200DS-S1 NSAA0RMST001
IC3002 IC 512MB DDR2 SDRAM K4T51163QJ-BCE7 NSCA0R0SM048
IC3006 IC 32M-BIT SERIAL FLASH MEMORY
W25Q32FVSSIG
NSCA0R0ZM018
IC3009 IC RESET IC-PST8429UR QSCA0T0MM075
IC3019 IC USB HIGH-SIDE SW AP2151WG-7/SOT25/
5PI
NSCA0TDES015
IC3101 Not used
IC3102 Not used
IC3103 Not used
IC3601 REGULATOR AP1117EG-13 NSCA0TDES012
IC3602 REGULATOR AP1117EG-13 NSCA0TDES012
IC3603 IC REGULATOR BD00IA5WEFJ-E2 QSCA0T0RM233
IC3605 IC DCDC CONVERTER RT8293ALZSP NSCA0T00B017
IC3607 Not used
IC3701 Not used
IC3801 IC D-CLASS AUDIO POWER AMPLIFI
TPA3110D2PWPR
NSCA0T0TY073
IC3803 Not used
IC3901 REGULATOR AP1117EG-13 NSCA0TDES012
TU3001 Not used
TU3901 TUNER UNIT U9001UH U9001UH
IC3401 Not used
IC3402 Not used
FUNCTION CBA UNIT A31T2MSW-001
POWER SUPPLY CBA A31T0MPW-002
C662 CAP ELE 22µF/50V/M/85 CEF2200V8006
C665 Not used
D662 Not used
IC651 IC REGULATOR AP1117E33G-13 /3PIN NSCA0TDES017
Q656 Not used
Q657 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q658 Not used
R662 Not used
R670 Not used
R671 Not used
R672 Not used
R676 METAL OXIDE FILM RES. 2W J 4.7 Ω RN024R7ZU001
R678 METAL OXIDE FILM RES. 2W J 4.7 Ω RN024R7ZU001
R679 METAL OXIDE FILM RES. 2W J 4.7 Ω RN024R7ZU001
R680 Not used
R681 Not used
R682 Not used
R683 RES CHIP 3216 1/4W J 3.9 Ω RRX43R9HH034
R684 RES CHIP 3216 1/4W J 3.9 Ω RRX43R9HH034
R685 RES CHIP 3216 1/4W J 3.3 Ω RRX43R3HH034
R686 RES CHIP 3216 1/4W J 3.3 Ω RRX43R3HH034
R687 RES CHIP 3216 1/4W J 3.3 Ω RRX43R3HH034
R688 RES CHIP 3216 1/4W J 2.2 Ω RRX42R2HH034
R689 RES CHIP 3216 1/4W J 2.7 Ω RRX42R7HH034
R690# Not used
Ref. No. Description Part No.
