Revision List
EN 2 TPM15.3HE LA1.
2015-Otc-09
back to
div.table
1. Revision List
Manual xxxx xxx xxxx.0
• First release
Manual xxxx xxx xxxx.1
• Chapter 6: Updated table 6-3 Display code overview
.
Manual xxxx xxx xxxx.2
• Chapter 2: Updated table 2.1 Technical Specifications
and connection 2.4 Connections (for 24"- 28" & 32"
3010W).
• Chapter 4: Added figure 4-4 Cable dressing (28" 5010
series) and 4-6 Cable dressing (32" 3010W series).
• Chapter 6: Updated table 6-2 White tone default settings
and 6-3 Display code overview
.
• Chapter 11: Added stytling sheets 11.4 5010 series 28"
and 11.6 3010W series 32"
.
Manual xxxx xxx xxxx.3
• Chapter 2: Updated table 2.1 Technical Specifications
and connection 2.3 Connections (for 19" 4010W).
• Chapter 4: Added figure 4-1 Cable dressing (19" 4010W
series) and added section 4.3 Assembly/Panel Removal
(for 19" 4010W ).
• Chapter 6: Updated table 6-2 White tone default settings
and 6-3 Display code overview
.
• Chapter 10: Added Circuit diagrams 10.13 AD 715G6350
LED Driver board.
• Chapter 11: Added stytling sheet 11.1 4010W series 19"
.
2. Technical Specs, Diversity, and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connections (for 19" 4010W)
2.4 Connections (for 24"- 28" & 32" 3010W)
2.5 Connections (for 32"- 55")
2.6 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in back to
div.table 2-1. Here is product information available, as well as
getting started, user manuals, frequently asked questions and
software & drivers.
Table 2-1 Described Model Numbers and Diversity
2.2 Directions for Use
Directions for use can be downloaded from the following
websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN
24 9 10 11
Connection Overview
Mechanics
Block Diagram
Schematics
Styling
Wire Dressing
Rear Cover Removal
SSB Removal
Power Supply
SSB
J (IR/LED panel)
E (Keyboard/Leading Edge)
HC (Option board)
AD (LED Driver board)
19HFL4010W/12 2-1 4-2 4-15 4-16 9.1 10.1 10.7 - - 10.12 10.13 11.1
24HFL3010T/12 2-6 4-2 4-15 4-16 9.1 10.1 10.7 10.8 - 10.12 - 11.2
24HFL3010W/12 2-6 4-2 4-15 4-16 9.1 10.1 10.7 10.8 - 10.12 - 11.2
28HFL3010T/12 2-6 4-3 4-15 4-16 9.1 10.2 10.7 10.8 - 10.12 - 11.3
28HFL5010T/12 2-6 4-4 4-15 4-16 9.1 10.2 10.7 10.8 - 10.12 - 11.4
32HFL3010T/12 2-13 4-5 4-17 4-18 9.1 10.3 10.7 10.9 10.11 10.12 - 11.5
32HFL3010W/12 2-6 4-6 4-17 4-18 9.1 10.2 10.7 10.9 - 10.12 - 11.6
32HFL5010T/12 2-13 4-7 4-17 4-18 9.1 10.4 10.7 10.10 10.11 10.12 - 11.7
32HFL5010T/60 2-13 4-7 4-17 4-18 9.1 10.4 10.7 10.10 10.11 10.12 - 11.7
32HFL5110K/12 2-13 4-8 4-17 4-18 9.1 10.4 10.7 10.10 10.11 - - 11.8
40HFL3010T/12 2-13 4-9 4-17 4-18 9.1 10.4 10.7 10.9 10.11 10.12 - 11.9
40HFL5010T/12 2-13 4-10 4-17 4-18 9.1 10.5 10.7 10.10 10.11 10.12 - 11.10
40HFL5010T/60 2-13 4-10 4-17 4-18 9.1 10.5 10.7 10.10 10.11 10.12 - 11.10
48HFL5010T/12 2-13 4-10 4-17 4-18 9.1 10.5 10.7 10.10 10.11 10.12 - 11.11
55HFL5010T/12 2-13 4-11 4-17 4-18 9.1 10.6 10.7 10.10 10.11 10.12 - 11.12
