Philips 40PFK4100/12 - Cable Dressing (24 4000 Series); Cable Dressing (24 PHH;T5210 Series)

Mechanical Instructions
EN 11TPN15.1E LA 4.
2015-Oct-30
back to
div. table
Figure 4-2 Cable dressing (24" 4000 series)
Figure 4-3 Cable dressing (24PHH/T5210 series)
19790_101.eps
CN601
CN401
CN9101
CN8604
CN701 CN408
MAIN POWER SUPPLY
(1054)
A
IR/LED BOARD
(1056)
J
SSB
(1053)
B
ECN701
ECN601
ECN408
ECN401
ECN401
ECN601
LOUDSPEAKER
(1184)
LOUDSPEAKER
(1184)
CN1
19794_100.eps
CN601
CN401
CN9101
CN8605
CN701
CN408
MAIN POWER SUPPLY
(1054)
A
SSB
(1053)
B
ECN701
ECN401
ECN601
ECN601
ECN408
ECN408
ECN401
ECN401
ECN401
ECN401
LOUDSPEAKER
(1184)
LOUDSPEAKER
(1184)
LED BOARD(Logo）
(1068)
ALC
IR/LED BOARD
(1056)
J
CN201
KEYBOARD CONTROL
(1057)
E
CN01
