Alignments
EN 41TPN15.1E LA 6.
2015-Oct-30
back to
div. table
This group setting of colour temperature will be applied
automatically to the TV / VGA / HDMI / AV sources.
Note: The information of the RGB value is only for reference,
the specific value is based on model adjustment.
6.4 Option Settings
6.4.1 Introduction
The microprocessor communicates with a large number of I
2
C
ICs in the set. To ensure good communication and to make
digital diagnosis possible, the microprocessor has to know
which ICs to address. The presence / absence of these
NT72567 ICs is made known by the option codes.
Notes:
• After changing the option(s), save them by pressing the OK
button on the RC before the cursor is moved to the left,
select STORE and press OK on the RC.
• The new option setting is only active after the TV is
switched “off” / “stand-by” and “on” again with the mains
switch (the NVM is then read again).
6.4.2 Option Code Overview
Enter SAM mode to check the option codes. they could not be
edited in the NVM.
6.4.3 Display Code Overview
Press the following key sequence on a standard RC
transmitter: “062598” directly followed by MENU and “xxx”,
where “xxx” is a 3 digit decimal value of the panel type: see
column “Display Code” in Table 6-3
. After resetting the Display
Code, restart the set immediately.
Table 6-3 Display code overview
Warm (6500K) 22PFH4000/88 128 102 74
22PFK4000/12 128 102 73
22PFT4000/12 127 102 74
22PFT4000/60 128 101 74
24PHH4000/88 127 102 72
24PHK4000/12 126 102 73
24PHT4000/12 127 101 73
24PHT4000/60 127 103 74
24PHH5210/88 127 123 114
24PHT5210/12 128 117 110
24PHK5210/12 127 122 111
24PHT5210/60 127 121 114
32PFH4100/88 127 96 58
32PFK4100/12 127 96 60
32PFT4100/12 127 94 60
32PFT4100/60 125 92 59
32PHH4100/88 127 121 120
32PHK4100/12 127 121 120
32PHT4100/12 126 120 119
32PHT4100/60 127 102 67
32PHH4200/88 126 119 120
32PHK4200/12 127 120 119
32PHT4200/12 126 118 118
39PFH4100/88 127 98 66
39PFK4100/12 127 98 67
39PFT4100/12 126 97 67
39PFT4100/60 127 98 67
39PFH4200/88 124 95 66
39PFK4200/12 125 97 63
39PFT4200/12 127 98 67
40PFH4100/88 127 111 72
40PFK4100/12 127 110 72
40PFT4100/12 126 110 72
40PFT4100/60 125 111 72
40PFH4200/88 127 112 71
40PFK4200/12 126 110 70
40PFT4200/12 127 111 72
40PFH6300/88 127 102 73
40PFK6300/12 126 101 74
40PFT6300/12 127 102 74
40PFT6300/60 127 100 72
48PFT4100/60 126 122 86
48PFH4100/88 127 123 87
48PFT4100/12 127 123 88
48PFK4100/12 126 121 88
48PFH6300/88 127 101 73
48PFK6300/12 125 100 74
48PFT6300/12 127 102 74
48PFT6300/60 126 101 72
55PFH6300/88 127 77 63
55PFK6300/12 126 76 63
55PFT6300/12 127 77 62
55PFT6300/60 126 75 61
Picture mode Screen size
Colour temperature
Red Green Blue
CTN_ALT BOM# Panel Type Display Code
22PFH4000/88 TPM215HW01-DAT01 008
22PFK4000/12 TPM215HW01-DAT01 008
22PFT4000/12 TPM215HW01-DAT01 008
22PFT4000/60 TPM215HW01-DAT01 008
24PHH4000/88 TPM236H3-BJ1L01.N 009
24PHH4000/88 TPM236WH2-BJ1P03.N 009
24PHK4000/12 TPM236H3-BJ1L01.N 009
24PHK4000/12 TPM236WH2-BJ1P03.N 009
24PHT4000/12 TPM236H3-BJ1L01.N 009
24PHT4000/12 TPM236WH2-BJ1P03.N 009
24PHT4000/60 TPM236H3-BJ1L01.N 009
24PHT4000/60 TPM236WH2-BJ1P03.N 009
24PHH5210/88 TPM236H3-BJ1L01.N SCAH 013
24PHH5210/88 TPM236WH2-BJ1P03.N SC1G 013
24PHT5210/12 TPM236H3-BJ1L01.N SCAH 013
24PHT5210/12 TPM236WH2-BJ1P03.N SC1G 013
24PHK5210/12 TPM236H3-BJ1L01.N SCAH 013
24PHK5210/12 TPM236WH2-BJ1P03.N SC1G 013
24PHT5210/60 TPM236H3-BJ1L01.N SCAH 013
24PHT5210/60 TPM236WH2-BJ1P03.N SC1G 013
32PFH4100/88 TPT315B5-EUJFFE S1E 004
32PFH4100/88 TPT315B5-HVN05.A S600G 020
32PFK4100/12 TPT315B5-EUJFFE S1E 004
32PFK4100/12 TPT315B5-HVN05.A S600G 020
32PFT4100/12 TPT315B5-EUJFFE S1E 004
32PFT4100/12 TPT315B5-HVN05.A S600G 020
32PFT4100/60 TPT315B5-EUJFFE S1E 004
32PFT4100/60 TPT315B5-HVN05.A S600G 020
32PHH4100/88 TPT315B5-DXJSFE SE1E 002
32PHH4100/88 TPT315B5-AN02.S S2D 019
32PHK4100/12 TPT315B5-DXJSFE SE1E 002
32PHK4100/12 TPT315B5-AN02.S S2D 019
32PHT4100/12 TPT315B5-DXJSFE SE1E 002
32PHT4100/12 TPT315B5-AN02.S S2D 019
32PHT4100/60 TPT315B5-0TU3A.Q S11D 003
32PHT4100/60 TPT315B5-WHBN0.K S5941B 021
32PHH4200/88 TPT315B5-DXJSFE SE1E 001
32PHH4200/88 TPT315B5-AN02.S S2D 019
32PHK4200/12 TPT315B5-DXJSFE SE1E 001
32PHK4200/12 TPT315B5-AN02.S S2D 019
32PHT4200/12 TPT315B5-DXJSFE SE1E 001
32PHT4200/12 TPT315B5-AN02.S S2D 019
39PFH4100/88 TPT400LA-J6PE1 SC1X 005
39PFK4100/12 TPT400LA-J6PE1 SC1X 005
