Circuit Descriptions
EN 43TPN15.1E LA 7.
2015-Oct-30
back to
div. table
7. Circuit Descriptions
Index of this chapter:
7.1 Introduction
7.2 Power Supply
7.3 DC/DC Converters
7.4 Front-End Analogue and DVB-T, DVB-C; ISDB-T reception
7.5 Front-End DVB-S(2) reception
7.6 HDMI
7.7 Video and Audio Processing - NT72453MBG-BA
7.8 Ambilight (only for 6300 series)
Notes:
•Only new circuits (circuits that are not published recently)
are described.
• Figures can deviate slightly from the actual situation, due
to different set executions.
• For a good understanding of the following circuit
descriptions, please use the wiring, block (see chapter
9. Block Diagrams
) and circuit diagrams (see chapter
10. Circuit Diagrams and PWB Layouts
).Where necessary,
you will find a separate drawing for clarification.
7.1 Introduction
The TPN15.1E LA is a new chassis launched in Europe in
2015. The whole range is covered by NT72453 platform.
The major deltas versus its predecessor support DVB-TC;
DVB-TC/T2; DVB-TC/S2 with also multi-media, ARC, CEC,
3D(for 6300), Ambilight(for 6300) function.
The TPN15.1E LA chassis comes with the following stylings:
• series xxPxx4100
• series xxPxx4200
• series xxPxx6300
• series xxPxx5210
7.1.1 Implementation
Key components of this chassis are:
• Scaler NT72453MBG-BA/B TFBGA-466 TV Processor for
4100/6300 series
• Scaler NT1912MBG-S/B TFBGA-364 TV Processor only
for 6300 series
• Tuner EU ST42CS-2-E for K/H/T models (DVB-C/T/T2)
• Tuner EU DNBU02112IH2 for K models ( DVB-S/S2)
• DEMODULATOR NT78822QG/A QFN-48 for T/T2
• AUDIO AD87588-LG48NAY 20W E-LQFP-48 150
7.1.2 TPN15.1E LA Architecture Overview
For details about the chassis block diagrams refer
to 9. Block Diagrams
. An overview architecture can be found in
Figure 9.1
.
