Mechanical Instructions
EN 10 TPN15.1E LA4.
2015-Oct-30
back to
div. table
4. Mechanical Instructions
Index of this chapter:
4.1 Cable Dressing
4.2 Service Positions
4.3 Assembly/Panel Removal (for 22"/24"Pxx4000)
4.4 Assembly/Panel Removal (for 32"/39"/40"Pxx4x00)
4.5 Assembly/Panel Removal (only for 32PHT4100/60)
4.6 Assembly/Panel Removal (for 6300 series)
4.7 Assembly/Panel Removal (for 24"PHx5210)
4.8 Set Re-assembly
Notes:
• Figures below can deviate slightly from the actual situation,
due to the different set executions.
4.1 Cable Dressing
Figure 4-1 Cable dressing (22" 4000 series)
19790_100.eps
CN601
CN401
CN9101
CN8601
CN701
CN408
MAIN POWER SUPPLY
(1054)
A
IR/LED BOARD
(1056)
J
SSB
(1053)
B
ECN701
ECN601
ECN408
ECN401
ECN401
ECN601
LOUDSPEAKER
(1184)
LOUDSPEAKER
(1184)
CN1
