Philips 40PFK4100/12 - 4000 Series 24

Styling Sheets
EN 141TPN15.1E LA 11.
2015-Oct-20
back to
div.table
11.2 4000 series 24"
19790_801.eps
4000 series 24"
Pos No. Description Remarks
0030 Bezel
0040 Rear cover
0050R Stand Assy-R
0050L Stand Assy-L
0095 V0 SHEET
1050 Display panel
1053 Panel SSB
1054 Power Supply Unit
1056 IR/LED panel
1176 Remote control Not displayed
1184 Speakers
FOR ELECTRICAL PARTS/ASSEMBLIES SEE WIRING DIAGRAM CHAPTER 9
1053
0030
1184
0040
0095
1054
0050L
1184
1056
1050
0050R
