Service Modes and Fault Finding
EN 13TPS15.3A LA 5.
2015-Oct-23
back to
div.table
5. Service Modes and Fault Finding
Index of this chapter:
5.1 Test Points
5.2 Service Modes
5.3 Stepwise Start-up
5.4 Software Upgrading
5.5 Fault Finding and Repair Tips
5.1 Test Points
As most signals are digital, it will be difficult to measure
waveforms with a standard oscilloscope.
Perform measurements under the following conditions:
• Service Default Mode.
• Video: Colour bar signal.
• Audio: 3 kHz left, 1 kHz right.
5.2 Service Modes
The Service Mode feature is split into one part:
• Factory Mode.
The Factory mode offer features, which can be used by the
Service engineer to repair/align a TV set. Some features are:
• Make alignments (e.g. White Tone), reset the error buffer
(Factory Mode).
Note: For the new model range, a new remote control (RC) is
used with some renamed buttons. This has an impact on the
activation of the Service modes. For instance the old “MENU”
button is now called “HOME” (or is indicated by a “house” icon).
5.2.1 Contents of the Factory mode:
Purpose
• To perform extended alignments.
Specifications
• Displaying and or changing Panel ID information.
• Various software alignment settings.
• Testpattern displaying.
• Public Broadcasting Service password Reset.
•etc.
How to Activate the Factory mode
To activate the Factory mode, use the following method:
• Press the following key sequence on the remote control
transmitter: from the “Menu” press “1999”, directly followed
by the “Back” button. Do not allow the display to time out
between entries while keying the sequence.
After entering the Factory mode, the following items are
displayed, the Default value just for reference.
Table 5-1 Factory mode overview
How to Exit the Factory mode
Use one of the following methods:
• Select EXIT from the menu and press the “OK” button.
Note: When the TV is switched “off” by a power interrupt, or
normal switch to “stand-by” while in the factory mode, the TV
will show up in “normal operation mode” as soon as the power
is supplied again. The error buffer will not be cleared.
Item Item value
Default value
Description49PUH6600/96 55PUH6600/96
0 Brand Philips-TWN Philips-TWN Brand name
1 Model 49PUH6600 55PUH6600 Model name
2 HW Ver 715G6546M1A001004K 715G6546M1A001004K Hardware version
3 SW Ver eg: 1.03_20150823_1203_49 eg: 2.02_20150918_0026_55 Software version
4 Date Sun Aug 23 Fri Sep 18 Software release date
5 Scaler MSD8590QV MSD8590QV Scaler name
6 Tuner TDSH-T070F TDSH-T070F Tuner name
7 Panel LVG490EQYM1AD82X0X LVA550QVN03AC52P0X Panel type
8 ADC Adjust Press OK to adjust Press OK to adjust ADC Adjust
9 W/B Adjust Press OK to adjust Press OK to adjust W/B Adjust
10 SSC Adjust Press OK to adjust Press OK to adjust SSC Adjust
11 EQ Adjust Press OK to adjust Press OK to adjust EQ Adjust
12 Burn In Off Off Burn In
13 Reset Press OK Press OK System Reset
14 Exit Press OK Press OK Exit factory mode
