Revision List
EN 2 TPS15.3A LA1.
2015-Oct-23
back to
div.table
1. Revision List
Manual xxxx xxx xxxx.0
• First release.
2. Technical Specs, Diversity, and Connections
Index of this chapter:
2.1 Technical Specifications
2.2 Directions for Use
2.3 Connections
2.4 Chassis Overview
Notes:
• Figures can deviate due to the different set executions.
• Specifications are indicative (subject to change).
2.1 Technical Specifications
For on-line product support please use the links in back to
div.table 2-1. Here is product information available, as well as
getting started, user manuals, frequently asked questions and
software & drivers.
Table 2-1 Described Model Numbers and Diversity
2.2 Directions for Use
Directions for use can be downloaded from the following
websites:
http://www.philips.com/support
http://www.p4c.philips.com
CTN
24 910 11
Connection Overview
Mechanics
Block
Diagrams Schematics
Styling
Wire Dressing
Rear Cover Removal
SSB Removal
Block Diagram
Power Supply
SSB
J (IR/LED)
E (Keyboard/Leading Edge)
TunerBox Board
49PUH6600/96 2-1 4-1 4-3 4-4 9.1 10.1 10.2 10.3 10.5 10.7 11.1
55PUH6600/96 2-1 4-2 4-3 4-4 9.1 10.1 10.2 10.4 10.6 10.7 11.2
