3. Mechanical Instructions
3.1 Cable dressing
Serial no
p
art descri
p
tion function
1 Back li
g
ht wire Connect to CN302
2 Power wire Connect to CN101
3 LVDS wire J455 to T-CON board
4 S
p
eaker wire CN210 to s
p
eaker
(y
ellow black wire
)
5 S
p
eaker wire CN202 to s
p
eaker
(
red black wire
)
6 two-terminal wire CN103 to IR board&LED
7 Supply line
CN203、CN101 to supply main board
8 WIFI line CN207 to WIFI board
1
7
CN101
6
CN101
J455
5
CN203
4
CN207
3
CN103
8
CN102
CN302
2
